AHD PNI House PTZ1350 Full HD video surveillance kit package with 4 outdoor cameras 2MP, 1080P and PNI SafeHouse 1TB included
|
Best picture qualityThe PNI House PTZ1350 AHD surveillance kit AHD PNI House PTZ1350 provides a top quality image so that the protected space is always safe. The 4 cameras included in the package can be mounted outdoors or indoors with ease. The metal casing and IP66 protection rating allows the cameras to be mounted in humid and dusty conditions. They have a Full HD 2MP (1920 x 1080) resolution and 36 IR LEDs provide night vision up to 30 meters. |
Local or remote real-time surveillanceBy plugging a monitor into the DVR's HDMI or VGA output, you can watch everything happening in the protected space in real time. Also through the monitor, access the DVR menu and make necessary system settings, update firmware or manage users. The PNI House PTZ1350 PTZ1350 package can be viewed and controlled remotely via the mobile app or using a computer (Windows OS). Download the XMEye app for Android and iOS or General CMS for Windows |
|
|
Recording typeThe PNI House PTZ1350 AHD surveillance kit supports a 3.5" HDD up to 14TB. We recommend installing a dedicated HDD for video surveillance. Thanks to the H.265+ video compression type, one of the most efficient, storage space is maximized without affecting video quality. The DVR/NVR can record in manual, scheduled, motion detection or alarm mode. The recording unit also supports PTZ, human or chip detection cameras. |
Optimal mountingThanks to 3 camera adjustment points (two at 360 degrees, one at 180 degrees) mounting is quick, easy and efficient allowing you to monitor even the tightest angles. You can connect not only the 4 AHD cameras included in the package to this DVR/NVR. It also supports network connection of IP cameras:
|
|
|
Complete packageThe PNI House PTZ1350 PTZ1350 AHD PNI House AHD Surveillance Kit is equipped with everything you need to get it up and running as soon as you open the packaging. The package contains:
|
Product identification | |
Manufacturer | PNI |
Product Code | PNI-PTZ1350 |
DVR/NVR Color | Black |
Camera Color | White |
DVR/NVR Features | |
Video Inputs | 4 x BNC |
Video Outputs | HDMI, VGA, Composite (BNC) |
Playback Resolution | 1080P(VGA) / 1080P(HDMI) |
Display mode | 1/4/9 |
Audio inputs | 4 x RCA |
Audio Outputs | 1 x RCA |
Audio compression | G711A |
Video compression | H.265 |
Data Storage | maximum 1 x 14TB HDD (not included) dedicated for video surveillance |
Network Interface | RJ45 10/100 Mbps |
Serial interface | 1 x RS485 |
Firmware upgrade | Yes, via USB |
Supply voltage | 12V/2A |
Power consumption | max. 15W (without HDD) |
Operating temperature | -26°C ~ +80°C |
Dimensions | 255 x 218 x 43 mm |
Recording resolution and number of channels, variants | Analog: 4 x 5M-N IP: 16 x 1080P / 8 x 5MP Hybrid: 4 x 5M-N + 2 x IP 1080P |
PTZ control | Supports |
USB ports | 2 x USB2.0 |
Dedicated application | XMEye |
Network | Yes, RJ45 LAN Port |
Recording modes | Manual, alarm, motion detection, scheduled |
Motion detection | Yes |
Chip detection | Yes |
Human form detection | Yes |
Camera Features | |
Pixels | 1920 × 1080 |
Resolution | 1080P |
Video Output | Analog, 75Ω, BNC connector |
Minimum Illumination | 0 Lux (IR on) |
Degree of protection | IP66, metal housing |
IR illumination distance | Up to 30 m |
Number of IR LEDs | 36 |
Power supply | 12V / 1A |
Lens | 3.6 mm |
Operating temperature | -26°C ~ +80°C |
Sensor resolution | 2MP |
Package contains | |
DVR / NVR | Yes |
Surveillance cameras | 4 indoor/outdoor cameras |
Camera connection cables | 4 x 18.3 m |
Power splitter | Yes, 1 x 4 |
Power supply NVR / DVR | 230V -> 12V 2A |
Software CD | |
User manual | Yes |
USB Mouse | Yes |
Remote control | |
Camera power supply | 230V -> 12V 4A |
