Antenna analyzer RigExpert AA-650 ZOOM, 0.1-650 MHz, color screen, with Bluetooth for connection with laptop, tablet or phone

AA-650 ZOOM

The RigExpert AA-650 ZOOM analyzer is designed for measuring SWR (standing wave ratio), return loss, cable defects, as well as other parameters of cable and antenna systems in the range from 100 kHz to 650 MHz.

The built-in ZOOM function makes graphic measurements particularly effective.

The Time Domain Reflectometer mode can be used to locate a fault in the power system.

The analyzer is equipped with a Bluetooth Low Energy module for a wireless connection to your laptop, tablet or smartphone.

Basic features

• 320×240 TFT color screen with high contrast and low power consumption
• Multilingual menu with help screens
• Accuracy in measurements without pre-calibration
• Zoom on the measurement curve
• Measuring the length of a cable
• Impedance measurement

Quick antenna check

• Tuning an antenna to resonance

• Comparative measurements before and after a certain situation (rain, storm, etc.)

• Manufacturing coaxial stubs and measuring their parameters

• Cable testing and fault location, attenuation and impedance measurement

• Measurement of capacitance and inductance of reactive loads

Portable analyzer

The RigExpert AA-650 ZOOM analyzer is portable and battery-operated, allowing you to perform tests directly on the test object.

The memory function (depending on model) allows you to quickly compare different antennas.

The USB port allows you to transfer measurement data to a computer. This is useful for conveniently storing and documenting measurement results over a long period of time, for example in small series production.
