Antenna CB PNI ML145 length 145 cm and magnet included PNI 145 / PL

Be the first to review this product

£19.01

Availability: In stock

SKU

PNI-ML145MAG

Details

	Performance CB antenna PNI ML145 The performance of the product is closely related to the technical characteristics that the antenna has in ideal conditions of installation and use: SWR <= 1.0, maximum power applied for a short time 400 W, impedance 50 Ohms, stainless steel, etc.
Communication distance The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 15 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the maximum legally allowed power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.
	Antenna length The length of the antenna is another very important factor that can influence the communication distance in traffic. Thus, the longer the antenna, the greater the range of action. The PNI ML145 CB antenna has a length of 145 cm.
Magnetic base The PNI 145/PL magnetic base has a diameter of 145 mm, a size that gives the antenna stability even at high speeds, having a pleasant design.
	Threaded fastening The PNI145/PL base is compatible with antennas that have an internal thread fastening system.
Cable length The length of the cable is an important factor in choosing a magnetic base. The base from PNI 145/PL has a quality cable with a length of 4 m, which allows placing the antenna on the dome of the car without any problem, and placing the cable so as not to disturb the passengers.
	Strong magnet The PNI145/PL base has a strong magnet for its size, which gives it a very good grip on the car dome, and resistance and stability even at high speeds.
Plug PL259 The PNI 145/PL magnetic base is equipped with RG58 coaxial cable and PL259 plug for direct connection to the station.
	Rubber support included In order to protect the car dome from possible scratches, but without affecting the operation of the antenna in optimal parameters, the magnetic base 145/PL is provided with a thin and resistant rubber support, which also protects the connections and solders inside it from water.

Reviews

Technical specifications

Product identification
Product code	PNIML145
Work tape	? B
Product color (spike)	Silver
General characteristics
Working frequency	26 - 28 Mhz
Number of channels	90
Maximum power applied	400W
Minimum SWR in the center of the band	1.0
Length	145 cm
Impedance	50 Ohms
Material	Stainless steel
Connector type	PL
Hole diameter	16 mm
Cable length	4 m
Weight	280 g
size	164x10x3 cm antenna 15x15x6 cm base
Working distance	15 km
Magnetic base	Magnetic base PNI 145/PL 145mm
The package contains
Magnetic base	145 mm

Download

PNI-ML145MAG

Lang	Type	Name	Link
EU	Declaration of Conformity	Declaratie de conformitate (ANTENA) EN, BG, DE, ES, FR, HU, IT, PL, RO	Link
EU	User manual	Manual de utilizare EN, ES, HU, IT, PL, RO	Link
