Antenna CB PNI S9 length 120 cm and butterfly magnet PNI 120 / DV 125 mm included

CB PNI S9 antenna kit and 125 mm magnet with 4m cable and plug pl259

£23.22

Availability: In stock

SKU

PNI-S9-120~DV

	CB antenna performance The performance of the product is closely related to the technical characteristics that the antenna has in ideal conditions of assembly and use: SWR <= 1.2:1, maximum applied power 600 W, impedance 50 Ohms, stainless steel, etc.
Communication distance The communication distance is another decisive factor in the acquisition and use of a CB antenna. Thus, the communication distance of 12-14 km is reached in ideal working conditions: calibrated antenna, open field without obstacles, the station with the maximum legally allowed power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can lead to a decrease in this distance.
	Antenna length The length of the antenna is another very important factor that can influence the communication distance in traffic. Thus, the longer the antenna, the greater the range. The antenna in this kit has a length of 137 cm (magnetic base included).
Magnetic base The magnetic base in this package is provided with a 4 m cable, long enough to place the antenna on the dome, and a diameter of 125 mm. The strong magnet gives the antenna stability even at very high speeds.
	Adjustable angle This antenna can be tilted with the help of the butterfly screw with which it is provided, to enter passages, garages or parking lots with low height. Apart from these situations, an inclination of more than 30 degrees is not recommended because it can affect the performance of the antenna.

Video presentation
CB PNI S9 antenna with butterfly, spike length 120 cm, without cable, 600W, 26 28MHz

Product identification
Product code	PNI-S9-120/DV
Workband	? B
Product color (spike)	Silver
General features
Working frequency	26 - 28 MHz
Number of channels	90
Maximum applied power	600W
Minimum SWR in the center of the band	less than 1.2:1
Length	120cm
Impedance	50 Ohms
Material	Stainless steel
Connector type	your
Weight	900g
size	142x10x3 cm; 13x13x9 cm
Working distance	12 km
The package contains
Radio station antenna	Yes
PL259 plug	Yes
Butterfly screw	Yes
Magnetic base	125mm
