Bax 20 pieces CB antennas PNI ML100, length 100 cm, 26-30MHz, 250W, 125mm magnet included

Bax 20 pieces CB antennas PNI ML100, length 100 cm, 26-30MHz, 250W, 125mm magnet included
£414.72
Availability: In stock
SKU
PNI-ML100-BX

performante Antena CB PNI ML100

Performance CB antenna PNI PNI ML100

The performance of the product is closely related to the technical characteristics that the antenna has in ideal conditions of installation and use: SWR <= 1.1, maximum applied power 250 W continuous, impedance 50 Ohms, stainless steel, etc.

Communication distance

Communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of maximum 12 km is reached under ideal working conditions: calibrated antenna, open field without obstacles, station with maximum legal admissible power of 4W and standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.

raza de actiune Antena CB PNI ML100

Antena CB PNI ML100 cu lungime 100 cm

Antenna length

Antenna length is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range. The PNI ML100 antenna is 110 cm long (magnetic base included).

Magnetic base

The magnetic base 120/PL in the package comes with a 4 m cable, sufficient for placing the antenna on the dome, has a diameter of 125 mm and a strong magnet which gives the antenna stability even at high speeds.

baza magnetica DV Antena CB PNI ML100

kit Antena CB PNI ML100

Complete package

This kit is ready to install and includes: antenna, magnetic base with cable and PL259 plug, magnet base with cable and PL259 socket, calibration bushing. All you need to do is to mount the antenna on the magnetic base, connect it to a CB radio station and calibrate it to use it at maximum performance.

Video presentation

CB PNI ML100 antenna EN

Write Your Own Review
You're reviewing:Bax 20 pieces CB antennas PNI ML100, length 100 cm, 26-30MHz, 250W, 125mm magnet included
Your Rating
Product identification
Product Code PNI-ML100
Working tape CB
Product color (herringbone) Silver
General Features
Operating frequency 26 - 28 Mhz
Number of channels 90
Maximum applied power 250W
Minimum S.W.R. in the center of the band 1,0
Length 100 cm (110 cm including base)
Impedance 50 Ohm
Material Stainless steel
Connector type PL
Hole diameter 16 mm
Cable length 4m
Weight 1.2 Kg
Dimensions 1000 x 150 x 40 mm
Gain 4 dBi
Working distance 12 km
Operating temperature -26°C ~ +80°C
Package contains
Radio antenna Yes
RG58 cable 4m
PL259 plug Yes
Magnetic base 125 mm



PNI-ML100
