Bax 30 pieces foldable CB PNI LED 1000 antennas, 80 cm long, with cable and butterfly fixed mount, 26-30 MHz, 300 Watt, illuminates during transmission
£562.82
Availability: In stock
SKU
PNI-LED1000-BX

Foldable CB PNI LED 1000 antenna

LED coil

The CB antenna PNI LED 1000 is the continuation of a new line of CB antennas, designed to make the use of the CB band unique. The antenna guarantees superior communication performance and improves visibility to the maximum.

The antenna coil is equipped with diodes that emit light when they are crossed by radio frequency. The coil lights up automatically when the radio emits, thus indicating the correct operation of the equipment. The higher the emission power, the higher the luminous intensity of the LEDs.

Length 80 cm

The CB antenna PNI LED 1000 with a length of 80 centimeters helps the emission and reception in the CB band at a distance of up to 10 km (in ideal conditions, without obstacles).

Factors influencing communication distance:
» Antenna length : longer antennas will have a greater range than shorter antennas.
» Mounting location : the higher the antenna is mounted, the better the range.
» Installation quality : installation mistakes, such as the lack of mass, will lead to a high SWR value and a limited range.
» The surrounding relief : The surrounding relief plays a huge role in determining the range of action. Obstacles, such as buildings or forested areas will limit the range of action.

Foldable CB PNI LED 1000 antenna

Foldable CB PNI LED 1000 antenna

Cable and mount for fixed attachment included

Thanks to the included accessories (butterfly type mount, RG58 cable and PL259 plug), mounting the antenna becomes a simple and fast thing:

» Connect the antenna to a separately purchased fixed support (for example: PNI SPA100 , PNI SPA110 , PNI L1 ) previously mounted on the car.
» Test the SWR in an open area using a reflectometer. In some cases it may be necessary to raise or shorten the wire to obtain an optimal SWR value. For optimal results, we recommend that this procedure, called calibration , be performed by authorized personnel with special equipment. Note: the PNI antennas are calibrated from the factory on the frequency 27.225Mhz (channel 22) .
» Connect the PL259 plug at the end of the antenna cable to the antenna plug on the back of the station.

Video presentation

PNI LED 1000 Foldable CB Antenna 100 cm Long UK

Write Your Own Review
You're reviewing:Bax 30 pieces foldable CB PNI LED 1000 antennas, 80 cm long, with cable and butterfly fixed mount, 26-30 MHz, 300 Watt, illuminates during transmission
Your Rating
Product identification
Product code PNI-LED1000
Work tape ? B
Product color (spike) Silver
Coil color Black
General characteristics
Working frequency 26 - 30 MHz
Maximum power applied 300W
Minimum SWR in the center of the band less than 1.2
Length 81 cm
Impedance 50 Ohms
Material Stainless steel
Cable length 4 m
Working distance 12 km
Operating temperature -26°C ~ +80°C
tiltable Yes, up to 90 degrees
The package contains
Radio station antenna Yes
RG58 cable Yes
Plug PL259 Yes
Fixed mounting mount Yes
