CB PNI antenna ML70, length 70cm, 26-30MHz, 200W, magnet 145 mm included

CB PNI ML70 antenna is a 145 mm magnet antenna included specifically dedicated to cars. It can be mounted very easily on both the dome and the trunk.

£17.61

Availability: In stock

SKU

PNI-ML70

	CB antenna performance PNI ML70 The performance of the product is closely related to the technical characteristics of the antenna in ideal conditions of installation and use: SWR <= 1.2, maximum applied power 200 W, impedance 50 Ohms, stainless steel, etc.
Communication distance The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of a maximum of 9 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.
	Antenna length The length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML70 antenna is 70 cm long (magnetic base included).
Magnetic base The magnetic base PNI 145/PL in the package is provided with a 4 m cable, sufficient for placing the antenna on the dome, it has a diameter of 145 mm and a strong magnet that gives the antenna stability even at high speeds.
	Complete package This kit is ready for assembly with: antenna, magnetic base with cable and plug PL259, Allen key for calibration. All you have to do is mount the antenna on the magnetic base, connect it to a CB radio station and calibrate it to use it at maximum performance.

Video presentation
CB PNI antenna ML70, length 70cm, 26 30MHz, 200W, magnet 145 mm included EN

Product identification
Product code	PNI-ML70
Work tape	? B
Product color (spike)	Black
General characteristics
Working frequency	26 - 28 Mhz
Number of channels
Maximum power applied	200W
Minimum SWR in the center of the band	less than 1.2
Length	70 cm (magnetic base included)
Impedance	50 Ohms
Material	Stainless steel
Connector type	PL
Hole diameter	16 mm
Cable length	4 m
Weight	800g
size	100 x 18 x 5 cm
Gain	4 dBi
Working distance	8 km
Operating temperature	-26°C ~ +80°C
The package contains
Radio station antenna	Yes
RG58 cable	4 m
Plug PL259	Yes
Magnetic base	145 mm
