CB PNI Escort HP 5500 radio station kit

CB PNI Escort HP 5500 radio station kit, 4W, 12V/24V, ASQ and PNI Extra 40 CB Antenna, SWR 1.0, fiberglass, with magnet

CB PNI Escort HP 5500 radio station kit

CB PNI Escort HP 5500 radio station kit and PNI Extra CB antenna 48, 45 cm, SWR 1.0, with magnet included

CB PNI Escort HP 5500 radio station and CB PNI Extra 45 antenna, 45 cm, SWR 1.0, 26-30MHz, 150W, black

CB PNI Escort HP 5500 radio station and CB PNI Extra 45 antenna, 45 cm, SWR 1.0, 26-30MHz, 150W, black
£59.72
Availability: In stock
SKU
PNI-PACK129

PNI-HP5500 - PNI Escort HP 5500 CB Radio Station, Multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, Cigarette Lighter Plug Included



statie radio cb, microfon, PNI

Simplicity for everyone

The PNI Escort HP 5500 CB radio station is ultra compact, measuring only 115 X 115 X 35 mm it can fit even in the smallest spaces.

Easy to install: just plug it into the cigarette lighter socket and the outdoor CB antenna mounted on the car's dome.

The PNI Escort HP 5500 has been designed with simplicity in mind, so anyone can use it with ease. The high-quality electret capacitor encapsulated in the microphone provides clear and powerful sound.

Important functions - anti-noise: SQ, ASQ and RF Gain

The PNI Escort HP 5500 CB radio station allows a faithful control over the background noise specific to the CB band.

The analog adjustable SQ function with the help of potentiometer and 5-level ASQ allow the user to filter and eliminate noise, making communication clearer.

The 7-level RF Gain function allows control over the reception frequency, reducing distortion.

Other features of the PNI Escort HP 5500 station: 4W transmitting power, 12-24V power supply, 40 channels, AM/FM modulation, emergency channels 9-19, 6-pin microphone connector, additional external speaker jack.

statie radio cb, microfon, PNI

statie radio cb, microfon, PNI

Multi-standard and multi-band CB station

By setting the norm and modulation, you can use the station in the UK and most European Union countries.

The PNI Escort HP 5500 is equipped with the main European bands (EU, CE, UK, PL, dE, in, i0, l2).

NOTE, to amend the rule:

1. Turn off the station; press the PTT key + the UP key on the microphone simultaneously while restarting the radio station

2. The LED corresponding to the A/F key lights up, and the current norm appears on the screen

3. Press the UP-DOWN keys to reach the desired norm, then restart the station or press the PTT key to exit the norm setting mode.

PNI-EXTRA45 - PNI Extra 45 CB antenna, with magnet included, length 45 cm, SWR 1.0, 26-30MHz, 150W, fiberglass



Discreet and efficient

The PNI Extra 45 antenna is the smallest CB antenna (it has a height of only 45 cm) that can be mounted on cars, vans or minibuses. Its small size makes it almost unnoticeable, easily confusing with the radio antenna.

Antena CB PNI Extra 45 cu magnet inclus SWR 1.0

Antena CB PNI Extra 45 cu magnet inclus SWR 1.0

Easy installation and calibration

The PNI Extra 45 antenna is easy to mount, by simply screwing the spike on the magnet fixed to the car dome, but also to calibrate, by rotating the tip with a screw, until the desired performance is obtained. It is recommended that the antenna adjustment/calibration be performed by specialized personnel with the related equipment.

Aerodynamic design

The PNI Extra 45 antenna has a special aerodynamic design that allows air to slide around the ear, eliminating wind noise.

Antena CB PNI Extra 45 cu magnet inclus SWR 1.0



Write Your Own Review
You're reviewing:CB PNI Escort HP 5500 radio station and CB PNI Extra 45 antenna, 45 cm, SWR 1.0, 26-30MHz, 150W, black
Your Rating

PNI-HP5500 - PNI Escort HP 5500 CB Radio Station, Multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, Cigarette Lighter Plug Included

Product Identification
Manufacturer NIP
Product code PNI-HP5500
Product Type CB radio station
General characteristics
Pattern Furniture
Transmission band type AM/FM
Channels 40
Frequency 26.965 - 27.405 MHz
Microphone Type (Pins) 6 pins
Speaker Audio Power 3 W
Sensitivity (20dB SINAD) FM -120 dBm, AM -118 dBm@ SINAD 12dB
Audio Signal Distortion less than 5% @ 1KHz
Transmitting power 4 W
Modulation FM: 2 KHz, AM: 80%
EEPROM Memory Yes
Power supply 12 V / 24 V
Dimensions (W x H x D / Weight) 115 X 115 X 35 mm / 611 gr
Special features
RF Gain Yes
ASQ Yes, 5 levels
Adjustable ASQ Yes
Emergency channels Yes
Digital Automatic Squelch (ASQ) Yes
Manual Squelch Yes
Accessory Connection 1-pin jack
Operating temperature -26°C ~ +80°C
Screen lighting
Display Type LCD
Rear panel connections
Additional speaker connection Yes
The package contains
Radio Station Yes
Microphone Yes
Radio station bracket and screws Yes
Microphone holder and screws Yes
Power Cord Yes
Cigarette lighter plug Yes
User Manual Yes


PNI-EXTRA45 - PNI Extra 45 CB antenna, with magnet included, length 45 cm, SWR 1.0, 26-30MHz, 150W, fiberglass

Product Identification
Product code NIP-EXTRA45
Work Tape CB
Product color (spike) Black
General characteristics
Working frequency 26 - 30 MHz
Number of channels 80
Maximum applied power 150W
Minimum S.W.R. in the center of the band 1,0
Length 45cm
Impedance 50 Ohm
Material Fiberglass
Connector Type PL
Cable length 4m
Weight 0.265 kg
Dimensions Height 50 cm
Polarization Vertical
Working distance 10 km
Operating temperature -26°C ~ +80°C
The package contains
Radio Station Antenna Yes
RG58 Cable Not
RG174 Cable Yes, 4 m
PL259 Plug Yes
Magnetic base Yes



PNI-EXTRA45
