PNI Escort HP 5500 CB radio station

CB PNI Escort HP 5500 radio station and CB PNI Extra 45 antenna, 45 cm, SWR 1.0, 26-30MHz, 150W, black

Package Radio station and CB antenna

CB radio station package PNI Escort HP 5500 and folding CB antenna PNI LED 1000, 80 cm, illuminates during the broadcast

CB PNI Escort HP 5500 radio station kit and PNI Extra CB antenna 48, 45 cm, SWR 1.0, with magnet included

CB PNI Escort HP 5500 radio station kit and PNI Extra CB antenna 48, 45 cm, SWR 1.0, with magnet included
£58.06
Availability: In stock
SKU
PNI-PACK128

PNI-HP5500 - CB radio station PNI Escort HP 5500, multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, cigarette lighter plug included



cb radio station, microphone, PNI

Simplicity for everyone

The PNI Escort HP 5500 CB radio station is ultra compact, measuring only 115 X 115 X 35 mm and can fit even in the smallest spaces.

Easy to install: just connect it to the cigarette lighter socket and the exterior CB antenna mounted on the car's dome.

The PNI Escort HP 5500 was designed with simplicity in mind, so that anyone can use it easily. The high-quality electret condenser encapsulated in the microphone provides clear and powerful sound.

Important functions - anti-noise: SQ, ASQ and RF Gain

The PNI Escort HP 5500 CB radio station allows for the most accurate control over the background noise specific to the CB band.

The analog adjustable SQ function with potentiometer and 5-level ASQ allow the user to filter and eliminate noise making communication clearer.

The 7-level RF Gain function allows control over the reception frequency, reducing distortion.

Other features of the PNI Escort HP 5500 station : 4W transmission power, 12-24V power supply, 40 channels, AM/FM modulation, emergency channels 9-19, 6-pin microphone connector, additional jack for external speaker.

cb radio station, microphone, PNI

cb radio station, microphone, PNI

Multistandard and multiband CB station

By setting the norm and modulation, you can use the station in the United Kingdom (UK) and most European Union countries.

The PNI Escort HP 5500 is equipped with the main European bands ( EU, CE, UK, PL, dE, in, i0, l2 ).

NOTE, to modify the rule:

1. Turn off the radio; simultaneously press the PTT key + the UP key on the microphone while turning the radio back on

2. The LED corresponding to the A/F key lights up and the current rate appears on the screen.

3. Press the UP-DOWN keys to reach the desired rate, then restart the station or press the PTT key to exit the rate setting mode.

PNI-EXTRA48 - CB antenna PNI Extra 48, with magnet included, 45 cm, 26-30MHz, 150W, SWR 1.0, fiberglass



Discreet and efficient

The PNI Extra 48 antenna is among the smallest CB antennas (it has a height of only 45 cm) and can be mounted on both cars and vans or minibuses. Its small dimensions make it almost unnoticeable, easily confused with a radio antenna. The average reception distance is 10 km.

CB antenna PNI Extra 45 with magnet included SWR 1.0

CB antenna PNI Extra 45 with magnet included SWR 1.0

Aerodynamic design

The PNI Extra 48 antenna has a special anti-noise design that allows air to slide around the spike, eliminating wind noise.

Write Your Own Review
You're reviewing:CB PNI Escort HP 5500 radio station kit and PNI Extra CB antenna 48, 45 cm, SWR 1.0, with magnet included
Your Rating

PNI-HP5500 - CB radio PNI Escort HP 5500, multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, cigarette lighter plug included

Product Identification
Manufacturer PNI
Product Code PNI-HP5500
Product Type CB radio
General Features
Model Mobile
Band type AM / FM
Channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 6 pin
Audio speaker power 3 W
Sensitivity (20dB SINAD) FM -120 dBm, AM -118 dBm@ SINAD 12dB
Audio signal distortion less than 5% @ 1KHz
Transmit Power 4 W
Modulation FM: 2 KHz, AM: 80%
EEPROM memory Yes
Power supply 12 V / 24 V
Dimensions (W x H x H / Weight) 115 X 115 X 35 mm / 611 gr
Special features
RF Gain Yes
ASQ Yes, 5 levels
Adjustable ASQ Yes
Emergency channels Yes
Automatic digital squelch (ASQ) Yes
Manual Squelch Yes
Accessory connection 1 pin jack
Operating temperature -26°C ~ +80°C
Display illumination
Display type LCD
Rear panel connections
Additional speaker connection Yes
Package contains
Radio Yes
Microphone Yes
Bracket and screws for radio Yes
Microphone mounting bracket and screws Yes
Power cable Yes
Lighter plug Yes
User manual Yes


PNI-EXTRA48 - CB Antenna PNI Extra 48, with magnet included, 45 cm, 26-30MHz, 150W, SWR 1.0, glass fiber

Product Identification
Product Code PNI-EXTRA48
Working band CB
Product color (spic) Black
General characteristics
Operating frequency 26 - 30 MHz
Maximum applied power 150W
Minimum S.W.R. in the center of the band 1,0
Length 45 cm (magnetic base included) Spigot length: 44 cm
Impedance 50 Ohm
Material Fiberglass
Connector type PL
Cable length 4m
Weight 193 g
Dimensions 450 x 103 x 66 mm
Gain >5 dBi
Polarization Vertical
Working distance 10 km
Magnetic base 103 x 66 x 40 mm
Operating temperature -26°C ~ +80°C
Package contains
Radio antenna Yes
RG174 cable Yes, 4 m
PL259 plug Yes



PNI-EXTRA48
Lang Type Name Link
EU10 Declaration of Conformity Declaration of conformity Link
EU10 User manual User manual EU10 Link
