CB PNI ESCORT HP 8024 ASQ Radio Station Pack + CB PNI Extra 48 Antenna with magnet
| Dual 12V / 24V power supplyThe CB PNI Escort HP 8024 radio station can be mounted both on cars with 12V power supply and on trucks or TIRs with 24V power supply. |
ASQ AdjustableAn innovation in the CB segment, the adjustable automatic squelch (ASQ), offers maximum comfort even for the most demanding users of car CB radio stations. If until now we were used to activating/deactivating the ASQ, now PNI brings its adjustment function, a function that allows the elimination of up to 100% of interference, background noise and jamming in the CB band. |
|
| ASQ button on microphoneFor increased comfort behind the wheel, PNI has positioned the automatic squelch (ASQ) activation/deactivation button on the microphone. Besides this, we also find the up/down buttons for changing channels. |
Key lock switchThe PNI Escort HP 8024 CB radio station has a switch on the front panel that allows the selection of the emergency channel (19), the normal operating mode (CH) and the activation of the key lock function (L), a useful function in situations where you want to avoid touching accidental pressing of the station keys. |
|
| Reduced dimensionsYou can use the product in any car, because it is one of the smallest CB radio stations on the market. Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing. |
Discreet and efficientThe PNI Extra 48 antenna is among the smallest CB antennas (it has a height of only 45 cm) and can be mounted both on cars and on vans or minibuses. Its small dimensions make it almost imperceptible, easily confusing with the radio antenna. The average reception distance is 10 km. |
|
| Aerodynamic designThe PNI Extra 48 antenna has a special anti-noise design that allows the air to slide around the spike, eliminating the noise produced by the wind. |
| Product identification | |
| Product code | PNI-PACK78 |
| General characteristics of the radio station | |
| Exemplary | Portable |
| Emission band type | AM-FM |
| Frequency | 26.965-27.405 MHz |
| channels | 40 AM/FM |
| Microphone type | 6 pins |
| Audio signal distortion | less than 8% @ 1 KHz |
| Emission power | 4W+ |
| Modulation | FM: 3KHz ± 0.2KHz, AM: 85-90% |
| Dimensions / Weight | 115 x 36 x 152 mm / 0.8 kg |
| Special radio station features | |
| ASQ (automatic squelch) | Yes |
| Lock the keyboard | Yes |
| Emergency channel button 9/19 | Yes |
| Operating temperature | -26 C - +60 C |
| Additional speaker connection | Yes |
| Characteristics of the radio antenna | |
| Working frequency | 26 - 28 Mhz |
| Maximum power applied | 150 W |
| Minimum SWR in the center of the band | 1.0 |
| Antenna length | 45 cm (magnetic base included) Spike length: 44 cm |
| Working distance | 10 km |
| Impedance | 50 Ohms |
| Material | Fiber glass |
| Connector type | PL259 |
| Magnetic base diameter | 103 x 66 x 40 mm |
| Cable length | 4 m |
| Gain | >5 dBi |
| Polarization | vertically |
| The package contains | |
| CB radio station | Yes |
| CB radio antenna | Yes |
| Magnetic base | Yes |
| Plug PL259 | Yes |
| Cigarette lighter plug | Yes |
| Microphone support | Yes |
| Station support | Yes |
| RG174 cable | Yes, 4 m |
| Microphone | Yes |
