CB PNI Escort HP 8900 Radio Station Package

CB PNI Escort HP 8900 ASQ Radio Station Package, 12-24V + CB PNI Extra 48 Antenna with Magnetic Base, 12V / 24V Power, RF Gain, Roger Beep, CTCSS-DCS, Dual Watch

CB PNI Escort HP 9700 USB radio station package and CB PNI LED 2000 antenna with magnetic base

CB PNI Escort HP 9700 USB Radio Station Package and CB PNI LED 2000 Antenna with magnetic base, 12V / 24V power supply, cigarette lighter plug included, ASQ 5 levels

CB PNI Escort HP 8900 ASQ Radio Station Package, 12-24V + CB PNI LED 2000 Antenna with Magnetic Base

CB PNI Escort HP 8900 ASQ Radio Station Package, 12-24V + CB PNI LED 2000 Antenna with Magnetic Base
£77.26
Availability: In stock
SKU
PNI-PACK108

PNI-HP8900 - CB radio station PNI Escort HP 8900 ASQ, 12V / 24V, RF Gain, Roger Beep, CTCSS-DCS, Dual Watch AM/FM switched only in the EU band



CB radio station PNI Escort HP 8900 ASQ, 12V

Multi-norm CB radio station

By changing the norm, the procedure is easy to execute with a simple combination of keys, and by changing the modulation (AM/FM) depending on the norm, the CB PNI Escort HP 8900 radio station can be used in several countries in Europe, such as Romania, Italy, Spain, UK, Germany, Poland, etc. Consult the legislation of each country regarding the use of the CB band, the maximum allowed emission power and the need or not to hold a license before using the PNI station.

Noise control functions: SQ, ASQ and RF Gain

The PNI Escort HP 8900 CB radio station allows the most faithful control over the background noise specific to the CB band. The 28-level adjustable SQ and 9-level adjustable ASQ function allow the user to filter and eliminate noises making communication clearer. The 9-level RF Gain function allows control over the reception frequency, reducing distortions.

CB radio station PNI Escort HP 8900 ASQ, 12V

CB radio station PNI Escort HP 8900 ASQ, 12V

1.77" color screen

The large color LCD screen (1.77 inches) displays information such as the current channel, frequency, modulation, signal strength (RX/TX), rate and active functions, being a reliable indicator of the station's operating status.

Additional settings menu

The MENU key on the front panel of the station allows direct access to the additional settings menu: screen brightness, key sound, automatic start, as well as activation, deactivation and setting of functions such as TOT, RF Gain, Noise Blanker, Roger Beep and CTCSS /DCS.

CB radio station PNI Escort HP 9700 USB ANC ASQ

PNI-LED20-BM - PNI LED 2000 CB antenna, 90 cm, with 145mm magnetic base, 26-28 MHz, 500 Watt, illuminates during transmission



LED coil

PNI LED 2000 brings an innovative element to the field of CB antennas: the coil of the antenna lights up when the station is broadcasting. The higher the emission power, the higher the luminous intensity of the LED.

LED2000-1

LED2000-1

performances

The performance of the PNI LED 2000 antenna is closely related to the technical characteristics that the antenna has in ideal conditions of installation and use: SWR < 1.2:1, maximum applied power 500 W, impedance 52 Ohms, stainless steel, etc.

Communication distance

Communication distance is another decisive factor when it comes to choosing a CB antenna. Thus, the maximum communication distance of 10 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as hills, mountains, buildings can reduce this distance.

LED2000-3

LED2000-4

Length

The length of the antenna is another important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. PNI LED 2000 has a length of 90 cm (coil+spike).

Accessories included

The package includes the 145 mm magnetic base that allows the antenna to be fixed on the car dome and connected to the radio station via the PL259 cable and plug.

LED2000-6

Video presentation

CB radio PNI Escort 8900 , 12V 24V, RF Gain, CTCSS DCS, Dual Watch UK

CB PNI LED 2000 antenna with SO 239 thread, length 90 cm, 26 28 MHz, 500 Watt, illuminates during

Write Your Own Review
You're reviewing:CB PNI Escort HP 8900 ASQ Radio Station Package, 12-24V + CB PNI LED 2000 Antenna with Magnetic Base
Your Rating

PNI-HP8900 - CB radio station PNI Escort HP 8900 ASQ, 12V / 24V, RF Gain, Roger Beep, CTCSS-DCS, Dual Watch AM/FM switched only in the EU band

Product identification
Producer PNI
Product code PNI-HP8900
Product type CB radio station
General characteristics
Exemplary Portable
Emission band type AM/FM
channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 6 pins
Speaker audio power 3 W
Sensitivity (20dB SINAD) 0.25 µV @ 12 dB SINAD
Emission power 4 W
EEPROM memory Yes
feeding 12 V / 24 V
Absorbed current 122 x 130 x 37 mm
Dimensions (W x H x D / Weight) 660 g
1DIN assembly Yes
Special features
Dual Watch Yes
Channel scan Yes
RF Gain Yes, 9 levels
ASQ Yes
Lock the keyboard Yes
ASQ adjustable Yes, on 9 levels
Emergency channels Yes
Roger Beep Yes
Noise filter NB (Noise Blanker) / HI CUT
Multicolor screen Yes, blue
Memory channels Yes
SWR meter Not
CTCSS / DCS (coder/decoder) Yes
Manual squelch Yes, 28 levels
and meter Yes
Accessory connection 1 pin plug
TOT (Time out Timer) Yes
Operating temperature -26°C ~ +80°C
Key sound Yes
Automatic start Yes
Display type LCD
Channel monitoring Yes
Display Yes
Use, destination In the car, truck or at home
Rear panel connections
Additional speaker connection Yes
Headphone connection Yes, 1 pin
The package contains
Radio station Yes
Microphone Yes
Support and screws for holding the radio station Yes
Microphone support and screws Yes
Power cord Yes
Cigarette lighter plug Yes
User manual Yes


PNI-LED20-BM - PNI LED 2000 CB antenna, 90 cm, with 145mm magnetic base, 26-28 MHz, 500 Watt, illuminates during transmission

Product identification
Product code PNI-LED20-BM
Work tape ? B
Product color (spike) Silver
Coil color Black
General characteristics
Working frequency 26 - 28 Mhz
Maximum power applied 500W
Minimum SWR in the center of the band less than 1.2:1
Length Spike length: 750 mm Antenna length: 900 mm
Impedance 50 Ohms
Material Stainless steel
Connector type PL
Cable length 4 m
Weight 1201 g
size Antenna: 44 x 44 x 900 mm Magnetic base: 145 x 145 x 60 mm
Working distance 10 km
Magnetic base Yes, 145mm
Operating temperature -26°C ~ +80°C
The package contains
Radio station antenna Yes
RG58 cable Yes, 4 m
Plug PL259 Yes
Magnetic base 145 mm



PNI-HP8900
Lang Type Name Link
EU Declaration of Conformity Declaration of conformity EN-BG-DE-ES-FR-HU-IT-PL-RO Link
EU10 User manual User manual EU10 Link

PNI-LED20-BM
Lang Type Name Link
EU10 Declaration of Conformity Declaration of conformity EU10 Link
