CB PNI Escort HP 8900 ASQ Radio Station Package, 12-24V + CB PNI ML70 Antenna, 70 cm with 145 mm magnetic base included
PNI-HP8900 - PNI Escort HP 8900 ASQ CB Radio Station, 12V/24V, RF Gain, Roger Beep, CTCSS-DCS, Dual Watch AM/FM switch to EU band only
|
|
Multi-norm CB radio stationBy changing the norm, the procedure easy to execute by a simple combination of keys, and by changing the modulation (AM/FM) according to the norm, the PNI Escort HP 8900 CB radio station can be used in several countries in Europe, such as Romania, Italy, Spain, UK, Germany, Poland etc. Consult the legislation of each country regarding the use of the CB band, the maximum allowed transmitting power and the need to hold or not a license before using the PNI station. |
Noise control functions: SQ, ASQ and RF GainThe PNI Escort HP 8900 CB radio station allows a more faithful control over the background noise specific to the CB band. The 28-level adjustable SQ and 9-level adjustable ASQ function allow the user to filter and eliminate noise, making communication clearer. The 9-level RF Gain function allows control over the reception frequency, reducing distortion. |
|
|
|
1.77" color screenThe large color LCD screen (1.77 inches) displays information such as current channel, frequency, modulation, signal strength (RX/TX), norm and active functions, being a reliable indicator of the station's operating status. |
Additional Settings MenuThe MENU key on the front panel of the station allows direct access to the menu of additional settings: screen brightness, key sound, automatic start, as well as activation, deactivation and setting of functions such as TOT, RF Gain, Noise Blanker, Roger Beep and CTCSS/DCS. |
|
PNI-EXTRA40 - PNI Extra 40 CB antenna, with magnet included, length 45 cm, 30W, 26-30MHz, SWR 1.0, fiberglass
Discreet and efficientThe PNI Extra 40 antenna is the smallest CB antenna (it has a height of only 44 cm - base included) that can be mounted on cars, vans or minibuses. Its small size makes it almost unnoticeable, easily confusing with the radio antenna. The average reception distance is 7 km. |
|
|
|
Easy installationThe Sirio Micro 60 CB antenna is easy to mount, by simply screwing the ear on the magnet fixed to the car dome. The antenna is pre-calibrated from the factory. |
Antenna performanceThe PNI Extra 40 antenna has the characteristics of a large antenna: SWR 1.0, impedance 50 Ohms, frequency 26-28 MHz. |
|
Video presentation |
|
CB radio PNI Escort 8900 , 12V 24V, RF Gain, CTCSS DCS, Dual Watch UK |
| Product identification | |
| Product code | PNI-PACK93 |
| General characteristics of the radio station | |
| Exemplary | Furniture |
| Emission band type | AM-FM |
| Frequency | 26.965-27.405 MHz |
| channels | 40 |
| Microphone type | 6 pins |
| Speaker audio power | 3W |
| Sensitivity (20dB SINAD) | 0.25 µV @ 12 dB SINAD |
| Emission power | 4W |
| 1 DIN mounting | Yes |
| feeding | 12 -24 V |
| Dimensions / Weight | 122 x 130 x 37 mm / 660 g |
| Special features of the radio station | |
| ASQ (automatic squelch) | Yes |
| Channel scan | Yes |
| RF Gain | Yes, 9 levels |
| Little Gain | Yes |
| Keyboard lock | Yes |
| Noise filter | NB (Noise Blanker) |
| Multicolor screen | Yes |
| Keyboard beep | Yes |
| Emergency channel button 9/19 | Yes |
| Additional speaker connection | Yes |
| Radio antenna features | |
| Working frequency | 26 - 28 MHz |
| Maximum applied power | 200W |
| Minimum SWR in the center of the band | less than 1.2 |
| Antenna length | 70 cm (magnetic base included) |
| Working distance | 8 km |
| Impedance | 50 Ohms |
| Material | Stainless steel |
| Connector type | PL259 |
| Hole diameter | 16 mm |
| Magnetic base included | Yes |
| Magnetic base diameter | 100 x 18 x 5 cm |
| Cable length | 4m |
| Gain | 4 dB |
| Polarization | vertically |
| The package contains | |
| CB radio station | Yes |
| CB radio antenna | Yes |
| Magnetic base | Yes |
| PL259 plug | Yes |
| RG58 cable | Yes |
| Station power cable | Yes |
| Fixed mount | Yes |
| Cigarette lighter socket | Yes |
| Microphone stand | Yes |
| Station support | Yes |
| Microphone | Yes |
| User manual | Yes |
