CB PNI ESCORT HP 9001 PRO ASQ 12/24 Radio Station Kit + CB PNI Extra 45 Antenna with Magnet
Dual power supply 12V-24V dcThe CB PNI Escort HP 9001 radio station can be mounted both on cars with 12V power supply and on trucks or TIRs with 24V power supply. | |
Automatic squelch | |
The PNI HP 9001 CB station offers its users the ASQ function, automatic squelch, which lends itself to most reception situations. On FM mode in a certain free channel the noise can be annoying. With the Squelch function you can reduce this noise, but at the same time also the signals that are too weak to be received properly. The squelch can also be adjusted from the ASQ button on the microphone. | |
6-pin microphone | |
The HP 9001 radio has a standard 6-pin microphone jack on the front panel. The microphone included in the package has buttons for channel selection, PTT button and ASQ activation button. | |
40 channels | |
The PNI HP 9001 radio station corresponds to the latest European CB standards. As a unique option, the station has a switch for changing the type of modulation (AM or FM), which will allow you to select the operating mode. | |
Multiple functions | |
The PNI HP 9001 radio station offers multiple functions for a complex use: the SCAN function for scanning channels, the MEM function for memorizing channels, the RF Gain function, for controlling the radio amplification at reception, the Dual Watch function, which allows monitoring two different channels and the ANL function , noise analyzer. | |
Multicolored illuminated screen | |
The PNI Escort HP 9001 ASQ station has a button (LCR) on the front panel for changing the color of the screen. The LCD screen illumination can be changed depending on the outside light, for easier use at night. | |
PNI Extra 45 antenna | |
The kit includes the PNI Extra 45 fiberglass antenna, with a maximum power of 150 W, magnet, RG58 cable and PL259 plug included. The length of 45 cm ensures an average radius of action of 10 km. |
Video presentation |
|
CB PNI Escort radio station HP 9001 PRO ASQ adjustable ENGThe CB PNI Extra 45 antenna |
Product identification | |
Product code | PNI-PACK90 |
General characteristics of the radio station | |
Exemplary | Portable |
Emission band type | AM-FM |
Frequency | 25.615 - 30.105 MHz |
channels | 40 AM/FM |
Microphone type | 6 pins |
Speaker audio power | 3 W |
Sensitivity (20dB SINAD) | less than 0.5 µV (AM/FM) |
Audio signal distortion | less than 5% @ 1 KHz |
Emission power | 4W+ |
Modulation | FM: 1.8KHz ± 0.2KHz, AM: 85-95% |
feeding | 12 -24 V |
Consumption | maximum 2200mA |
Dimensions / Weight | 46 x 142 x 158mm / 500g |
Special radio station features | |
ASQ (automatic squelch) | Yes |
Channel scan | Yes |
Lock the keyboard | Yes |
CSF | Yes |
Memory channels | Yes |
Noise filter | ANL (Automatic Noise Limiter) |
Multicolor screen | Yes |
Emergency channel button 9/19 | Yes |
Dual watch | Yes |
Characteristics of the radio antenna | |
Working frequency | 26.965 - 27.405 Mhz |
Number of channels | 80 |
Maximum power applied | 150 W |
Minimum SWR in the center of the band | 1.0 |
Antenna length | 45 cm |
Impedance | 50 Ohms |
Material | Fiber glass |
Connector type | PL259 |
Magnetic base included | Yes |
Magnetic base diameter | 90 mm |
Cable length | 4 m |
The package contains | |
CB radio station | Yes |
CB radio antenna | Yes |
Magnetic base | Yes |
