PNI Escort HP 9700 and CB Antenna PNI Extra 45

CB PNI Escort HP 9700 USB Radio Station Package and CB PNI Extra 45 Antenna with magnetic base

CB PNI Escort HP 8900 Radio Station Package

CB PNI Escort HP 8900 ASQ Radio Station Package, 12-24V + CB PNI Extra 48 Antenna with Magnetic Base, 12V / 24V Power, RF Gain, Roger Beep, CTCSS-DCS, Dual Watch

CB PNI Escort HP 9700 USB Radio Station Package and CB PNI Extra 48 Antenna with magnetic base

CB PNI Escort HP 9700 USB Radio Station Package and CB PNI Extra 48 Antenna with magnetic base
£70.23
Availability: In stock
SKU
PNI-PACK106

PNI-HP9700USB - CB radio station PNI Escort HP 9700 USB, ANC, ASQ, 12V / 24V power supply, cigarette lighter plug included



CB radio station PNI Escort HP 9700 USB ANC ASQ

Multi-norm CB radio station

By changing the norm, the procedure is easy to execute with a simple combination of keys, and by changing the modulation (AM/FM) depending on the norm, the PNI Escort HP 9700 CB radio station can be used in several countries in Europe, such as Romania, Italy, Spain, UK, Germany, Poland etc. Consult the legislation of each country regarding the use of the CB band, the maximum allowed emission power and the need or not to hold a license before using the PNI station.

Noise control functions: SQ, ASQ, RF Gain and ANC

The PNI Escort HP 9700 CB radio station allows the most faithful control over the background noise specific to the CB band. The adjustable SQ function on 28 levels and ASQ on 5 levels allow the user to filter and eliminate noises making communication clearer. The 9-level RF Gain function allows control over the reception frequency, reducing distortions. The ANC (Automatic Noise Cancelling) function automatically extracts and cancels the noise level on the reception.

CB radio station PNI Escort HP 9700 USB ANC ASQ

CB radio station PNI Escort HP 9700 USB ANC ASQ

Scan, Lock, EMG and USB port

The PNI Escort HP 9700 is a station that easily meets the basic needs of any CB band user. The channel scan function, key lock and immediate access to emergency channels (9/19) through the dedicated button make the HP 9700 an accessible, intuitive and easy-to-set station. The USB 5V 1.7A connector on the front panel offers the possibility of charging mobile devices.

Settings menu

The RFG/MENU key on the front panel allows direct access to the additional settings menu: setting the RF Gain level, activating/deactivating the ANC function, setting the brightness level and screen contrast.

CB radio station PNI Escort HP 9700 USB ANC ASQ

PNI-EXTRA48 - PNI Extra 48 CB antenna, with magnet included, 45 cm, 26-30MHz, 150W, SWR 1.0, fiberglass



Discreet and efficient

The PNI Extra 48 antenna is among the smallest CB antennas (it has a height of only 45 cm) and can be mounted both on cars and on vans or minibuses. Its small dimensions make it almost imperceptible, easily confusing with the radio antenna. The average reception distance is 10 km.

CB antenna PNI Extra 45 with magnet included SWR 1.0

CB antenna PNI Extra 45 with magnet included SWR 1.0

Aerodynamic design

The PNI Extra 48 antenna has a special anti-noise design that allows the air to slide around the spike, eliminating the noise produced by the wind.

Video presentation

CB PNI Escort HP 9700 USB, ANC, ASQ radio station, 12V 24V power supply UK

Write Your Own Review
You're reviewing:CB PNI Escort HP 9700 USB Radio Station Package and CB PNI Extra 48 Antenna with magnetic base
Your Rating

PNI-HP9700USB - CB radio station PNI Escort HP 9700 USB, ANC, ASQ, 12V / 24V power supply, cigarette lighter socket included

Product identification
Producer PNI
Product code PNI-HP9700USB
Product type CB radio station
General characteristics
Exemplary Portable
Emission band type AM/FM
channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 6 pins
Sensitivity (20dB SINAD) greater than 1 µV AM/FM
Emission power 4 W
Modulation 70% - 90% (AM) / 1.9KHz (FM)
feeding 12 V / 24 V
Dimensions (W x H x D / Weight) 115 x 150 x 38 mm / 0.8 kg
1DIN assembly Yes
Special features
Channel scan Yes
RF Gain Yes, 9 levels
ASQ Yes, 5 levels
Lock the keyboard Yes
Emergency channels Yes
Noise filter ANC (Automatic Noise Cancelling)
Multicolor screen Blue
Manual squelch Yes, 28 levels
Operating temperature -26°C ~ +80°C
Display type LCD
Channel monitoring Yes
Display Yes
Use, destination in the car, truck, or at home
Rear panel connections
Additional speaker connection Yes
Front panel connections
USB port Yes
The package contains
Radio station Yes
Microphone Yes
Support and screws for holding the radio station Yes
Microphone support and screws Yes
Power cord Yes
Cigarette lighter plug Yes
User manual Yes


PNI-EXTRA48 - PNI Extra 48 CB antenna, with magnet included, 45 cm, 26-30MHz, 150W, SWR 1.0, fiberglass

Product identification
Product code PNI-EXTRA48
Work tape ? B
Product color (spike) Black
General characteristics
Working frequency 26 - 30 MHz
Maximum power applied 150W
Minimum SWR in the center of the band 1.0
Length 45 cm (magnetic base included) Spike length: 44 cm
Impedance 50 Ohms
Material Fiber glass
Connector type PL
Cable length 4 m
Weight 193 g
size 450 x 103 x 66 mm
Gain >5 dBi
Polarization vertically
Working distance 10 km
Magnetic base 103 x 66 x 40 mm
Operating temperature -26°C ~ +80°C
The package contains
Radio station antenna Yes
RG174 cable Yes, 4 m
Plug PL259 Yes



PNI-EXTRA48
Lang Type Name Link
EU10 Declaration of Conformity Declaration of conformity Link
EU10 User manual User manual EU10 Link
