| CB antenna performanceThe performance of the product is closely related to the technical characteristics of the antenna under ideal conditions of installation and use: SWR <= 1.2:1, maximum applied power 250 W, impedance 50 Ohms, stainless steel, etc. |
Communication distanceThe communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of 10 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the maximum legally allowed power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can lead to a decrease in this distance. |
|
| Antenna lengthThe length of the antenna is another very important factor that can influence the communication distance in traffic. Thus, the longer the antenna, the greater the range. The antenna in this kit has a length of 76 cm (magnetic base included). |
Magnetic baseThe magnetic base in this package is equipped with a 4 m cable, long enough to place the antenna on the dome, and a diameter of 125 mm. The strong magnet gives the antenna stability even at very high speeds. |
|
| Adjustable angleThis antenna can be tilted using the included thumbscrew to enter low-height passages, garages, or parking lots. Outside of these situations, a tilt greater than 30 degrees is not recommended as it may affect the antenna's performance. |
CB radio station kit PNI Escort HP 2020 single channel 22 with CB antenna PNI S75 with magnet
PNI-HP2020 - CB radio station PNI Escort HP 2020 single channel 22 frequency 27.225 MHz, noise-free, probably the quietest station.
| One channel, one frequencyThe PNI Escort HP 2020 CB station is the latest innovation from the PNI brand. The station comes factory preset on a single frequency, 27.225 MHz, a single modulation (FM) and a single channel, channel. no. 22. The PNI Escort HP 2020 CB station is dedicated to use exclusively in Romania. |
Basic functionsEquipped with basic functions, automatic and manual Squelch control, the PNI Escort HP 2020 station becomes extremely easy to use. You just have to power it (12V) and connect it to a calibrated external antenna. Press the PTT button and start transmitting immediately. Forget about the problem of setting the various functions that CB stations are usually equipped with. Activate the squelch manually or automatically only if necessary, depending on the background noise on the band. |
|
| In shortPNI Escort HP 2020 is a simple station, reduced to basic functions. With LED indicators for operating status (on/off) and for transmission/reception status, PNI HP 2020 truly becomes an indispensable device for drivers, without additional settings, without setting the norm and channel, without activating/deactivating functions. You install it, power it and fully enjoy all the advantages of CB communication. |
PNI-S75 - CB antenna PNI S75 with butterfly, 26-28MHz, spike length 54 cm, 125mm magnet included
Video presentation |
|
CB PNI Escort HP 2020 single channel 22 radio station UK |
PNI-HP2020 - CB radio station PNI Escort HP 2020 single channel 22 frequency 27.225 MHz, noise-free, probably the quietest station. | |
|---|---|
| Product identification | |
| Producer | PNI |
| Product code | PNI-HP2020 |
| Product type | CB radio station |
| General features | |
| Exemplary | Portable |
| Emission band type | FM |
| channels | Channel No. 22 |
| Frequency | 27.225 MHz |
| Speaker audio power | 2W |
| Sensitivity (20dB SINAD) | -120 dBm |
| Emission power | 4W |
| feeding | 12V |
| Dimensions (W x H x D / Weight) | 115 x 150 x 35 mm / 513 g |
| 1DIN mounting | Yes |
| Special features | |
| Adjustable ASQ | |
| Automatic digital squelch (ASQ) | Yes |
| Manual squelch | Yes |
| Operating temperature | -26°C ~ +80°C |
| Rear panel connections | |
| Additional speaker connection | Yes |
| The package contains | |
| Radio station | Yes |
| Microphone | Yes |
| Radio station mounting bracket and screws | Yes |
| Microphone holder and screws | Yes |
| Cigarette lighter socket | Yes |
| User manual | Yes |
PNI-S75 - CB antenna PNI S75 with butterfly, 26-28MHz, spike length 54 cm, 125mm magnet included | |
|---|---|
| Product identification | |
| Product code | PNI-S75 |
| Work tape | ? B |
| Product color (spike) | Silver |
| General features | |
| Working frequency | 26 - 28 MHz |
| Number of channels | |
| Maximum applied power | 250W |
| Minimum SWR in the center of the band | less than 1.2:1 |
| Length | 76 cm including base |
| Impedance | 50 Ohms |
| Material | Stainless steel |
| Connector type | PL |
| Cable length | 4m |
| Polarization | vertically |
| Working distance | 10 km |
| Operating temperature | -26°C ~ +80°C |
| The package contains | |
| Radio station antenna | Yes |
| RG58 cable | 4 m |
| PL259 plug | Yes |
| Butterfly screw | Yes |
| Magnetic base | 125mm |
