CB PNI Escort HP 8001L ASQ radio station package

PNI Escort HP 8001L ASQ CB Radio Station Package + Microphone and PNI Mike 80 Bluetooth Dongle

PNI Escort HP 7120 CB radio station and microphone

CB radio station kit PNI Escort HP 7120 ASQ with CB antenna PNI Extra 48 and additional microphone Dongle with Bluetooth PNI Mike 65 included

CB radio station PNI Escort HP 6500 and additional microphone Dongle with Bluetooth PNI Mike 65 included

CB radio station PNI Escort HP 6500 and additional microphone Dongle with Bluetooth PNI Mike 65 included
£70.50
Availability: In stock
SKU
PNI-PACK116

PNI-HP-6500 - CB radio station PNI Escort HP 6500, multistandard, 4W, AM-FM, 12V, ASQ, RF Gain, cigarette lighter plug included AM/FM switched only in the EU band



PNI Escort HP 6500 CB radio station

Simplicity with maximum effect

The Escort HP 6500 is the new ultra-compact radio station from PNI. Measuring just 110 X 120 X 28 mm, the station can fit even in the smallest spaces.

Easy to install : just connect it to the cigarette lighter socket and the outdoor antenna mounted on the car's dome.

The PNI Escort HP 6500 CB radio station was designed with simplicity in mind, so that anyone can use it easily. The high-quality electret condenser encapsulated in the microphone provides clear and powerful sound.

By intelligently designing the circuits on the motherboard and integrating new components, including a state-of-the-art processor, the PNI Escort HP 6500 is now even more reliable, with even better performance.

The PNI Escort HP 6500 is designed to give you trouble-free communication every day. From the advanced circuitry inside to the durable metal chassis, the HP 6500 can give you the superior performance you would expect from a PNI station.

Multistandard and multiband CB station, use in the UK and anywhere in Europe, AM/FM modulation

By setting the norm and modulation, you can use the station in the UK and most European Union countries.

The PNI Escort HP 6500 is equipped with the main European bands ( EU, CE, UK, PL, I, I2, dE, In ) and with AM/FM operation.

Note: Before changing the modulation, check the selected standard. If the selected standard does not support AM modulation (such as, for example, CE, UK and dE 41CH-80CH standards), pressing the A/F key on the station will have no effect .

PNI Escort HP 6500 CB radio station

PNI Escort HP 6500 CB radio station

Dual squelch, SQ and ASQ. RF Gain function

The PNI Escort HP 6500 is enhanced with a 9-level configurable automatic digital Squelch and 28-level configurable manual Squelch . The RF Gain function (for controlling radio amplification during reception) is also configurable on 9 levels.

Functions at a glance : 4W transmission power, 12V power supply, 40 channels, AM/FM modulation, emergency channels 9-19, RJ11 microphone connector, additional jack for external speaker.

PNI VX6500, microphone compatible with VOX function and ANC filter

The VOX function allows the CB user to transmit automatically without pressing the PTT (Push-to-Talk) key. Transmission is activated when the sound (voice) exceeds a certain level.

To avoid accidental emission, the PNI VX6500 microphone has two VOX emission adjustment functions:

- VOX sensitivity adjustment function . 4 sensitivity levels are available. We recommend setting the microphone to sensitivity level 1 (the least sensitive), to avoid unintentional activation of the transmission in the presence of background sounds or secondary conversations.

- VOX delay adjustment function . This function sets the time between when you start talking and when the transmission is activated. There are 4 levels available. The shortest time is on level 1.

The PNI VX6500 microphone can be purchased separately.

PNI Escort HP 6500 CB radio station

PNI-MIKE65 - Microphone and Bluetooth Dongle PNI Mike 65, dual channel, compatible with PNI HP 6500, PNI HP 6550, PNI HP 7120



Radio station, CB, Microphone, wireless, dongle, PNI, bluetooth

Dual channel radio communication via Bluetooth

PNI improves the comfort of CB radio communication through the new product Wireless Microphone and Bluetooth Dongle Mike 65 specially designed for the PNI Escort HP 6500, PNI Escort HP 6550 and PNI Escort HP 7120 radio stations, but also for any other station with power supply via the RJ11 connection.

The microphone and dongle can communicate wirelessly with the CB radio station up to a maximum distance of 10 m . You can power the radio station from the cigarette lighter socket in the trunk or from the rear seats, and the driver will transmit and receive only using the Mike 65 wireless microphone .

A special feature is the possibility of simultaneous dual channel connection with the radio station and a mobile phone. With the built-in microphone with speaker Mike 65 you can answer and talk on the phone just by pressing the PTT button on the microphone.

Radio station, CB, Microphone, wireless, dongle, PNI, bluetooth

Fast connection without interference

Connecting the wireless microphone to other Bluetooth devices is quick and easy. You will receive messages through the microphone speaker confirming the closing and opening of the microphone, the establishment or loss of the Bluetooth connection.

The wireless microphone with integrated speaker includes a 3.7V 1200 mAh battery that allows you to use it for up to 8 hours. To power it, use the USB-Jack 3.5mm cable included in the package, connected to a USB port.

The Bluetooth dongle does not include a battery, it is powered directly from the radio station's RJ11 connector.

For discreet communication, the Mike 65 microphone can be replaced with the PNI BT-MIKE 7500 Bluetooth Headset with Microphone with PTT (not included) .

Radio station, CB, Microphone, wireless, dongle, PNI, bluetooth

Write Your Own Review
You're reviewing:CB radio station PNI Escort HP 6500 and additional microphone Dongle with Bluetooth PNI Mike 65 included
Your Rating

PNI-HP-6500 - PNI Escort HP 6500 CB radio station, multistandard, 4W, AM-FM, 12V, ASQ, RF Gain, cigarette lighter plug included, AM/FM switched only in the EU band

Product identification
Producer PNI
Product code PNI-HP-6500
General characteristics
Model Portable
Emission band type AM/FM
channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) RJ11
Speaker audio power 1W
Sensitivity (20dB SINAD) greater than 1 µV AM/FM
Emission power 4 W
Modulation 80-90%
feeding 12 V
Absorbed current 2A maximum
Dimensions (W x H x D / Weight) 110 X 110 X 25 mm / 385 g
1DIN assembly Yes
Special features
Channel scan Yes
RF Gain Yes, 9 levels
ASQ
Lock the keyboard Yes
ASQ adjustable Yes, 28 levels
Emergency channels Yes
Multicolor screen Blue
Automatic Digital Squelch (ASQ) Yes, 9 levels
Manual squelch Yes
and meter Yes
Operating temperature -26°C ~ +80°C
Rear panel connections
Additional speaker connection Yes
The package contains
Radio station Yes
Microphone Yes
Support and screws for holding the radio station Yes
Microphone support and screws Yes
Power cord Yes
Cigarette lighter plug Yes
User manual Yes
1DIN mounting case


PNI-MIKE65 - PNI Mike 65 Bluetooth Microphone and Dongle, dual channel, compatible with PNI HP 6500, PNI HP 6550, PNI HP 7120

Product identification
Producer PNI
Product code PNI-MIKE65
Characteristics
Plug type RJ11
Bluetooth Yes
Frequency 2.4GHz
feeding Li-Ion battery 3.7V 1200mAh
Duration of operation Up to 8 hours
Compatibility PNI Escort HP 6500, PNI Escort HP 7120
Range Up to 10 m
size Microphone: 90 x 43 x 58 mm Dongle: 40 x 28 x 17 mm
Weight Microphone: 113 g (battery included) Dongle: 8 g
loudspeaker Yes, built in
The package contains
Microphone Yes
Dong Yes
USB cable Yes
Battery Yes, 1200mAh
User manual Yes



PNI-HP-6500
Lang Type Name Link
EU10 Declaration of Conformity Declaration of conformity Link
EU10 User manual User manual EU10 Link
