Radio amateur station PNI Escort HP 6755

Radio amateur station PNI Escort HP 6755

Portable CB radio PNI Escort HP 102, multi standard, 4W, 12V, AM-FM, NRC, Dual Watch, Roger Beep, ASQ SQ adjustable

Portable CB radio station PNI Escort HP 102, multi standard, 4W, 12V-24V, AM-FM, NRC, Dual Watch, Roger Beep, adjustable ASQ SQ, VOX

CB radio station PNI Escort HP 6800 ASQ, 12/24 V, MP3 player, USB plug, 4W, AM-FM, cigarette lighter plug included

CB radio station PNI Escort HP 6800 ASQ, 12/24 V, MP3 player, USB plug with charging function for mobile devices, 4W, AM-FM, cigarette lighter plug included
£58.06
Availability: In stock
SKU
PNI-HP-6800

Statie radio CB PNI Escort HP 6800 ASQ, 12/24V

PNI Escort HP 6800 CB Radio Station

The PNI Escort HP 6800 CB radio station is a high-performance device for CB (Citizen Band) communications, ideal for truck drivers, cars, but also for users who want an efficient radio communication solution over medium and long distances.

Dual power supply 12V/24V

The station can be powered at both 12V and 24V, making it compatible with most cars, trucks, coaches, and other commercial vehicles.

Statie radio CB PNI Escort HP 6800 ASQ, 12/24V

Statie radio CB PNI Escort HP 6800 ASQ, 12/24V

SQ (Squelch) and ASQ (Auto Squelch) function

Manual SQ (Squelch): Allows the user to manually adjust the signal filter threshold, eliminating unwanted background noise.

ASQ (Automatic Squelch): Automatic adjustment to eliminate noise, allowing for clearer reception without constant manual intervention.

5V/0.5A USB port – Phone charging and MP3 playback

The station is equipped with a 5V/0.5A USB port, which allows:

  • Charging a smartphone or other mobile devices.
  • Playing MP3 files from a USB stick, also functioning as a media player.

Statie radio CB PNI Escort HP 6800 ASQ, 12/24V

Statie radio CB PNI Escort HP 6800 ASQ, 12/24V

Multi-standard – 7 operating rules

The PNI Escort HP 6800 CB radio station is designed for use in multiple countries by selecting one of the 7 norms (CB standards).

By changing the rule, the user can adjust the frequencies, channels and emission limits according to the legislation of the respective country.

This feature is useful for drivers who frequently travel abroad, allowing them to use the station in whatever country they are in, in accordance with local regulations.



Write Your Own Review
You're reviewing:CB radio station PNI Escort HP 6800 ASQ, 12/24 V, MP3 player, USB plug, 4W, AM-FM, cigarette lighter plug included
Your Rating
Product identification
Producer NIP
Product code PNI-HP-6800
Product type CB radio station
General features
Exemplary Furniture
Emission band type AM/FM
channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 6 pins
Speaker audio power 3W
Sensitivity (20dB SINAD) 0.8uV -113 dBm FM / 1.5uV -103 dBm AM
Audio signal distortion less than 5% @ 1KHz
Emission power 4W
feeding 12V / 24V
Dimensions (W x H x D / Weight) 140 X 125 X 40 mm / 1,096
Special features
Channel scan Yes
ASQ Yes
Manual squelch Yes
Accessory connection 1-pin plug
Operating temperature -26°C ~ +80°C
Emergency function Yes
Screen lighting Yes
Key illumination Yes
Display type LCD
Display Yes
MP3 Player Yes
Rear panel connections
Additional speaker connection Yes
Front panel connections
USB port Yes
The package contains
Radio station Yes
Microphone Yes
Radio station mounting bracket and screws Yes
Microphone holder and screws Yes
Power cable Yes
Cigarette lighter socket Yes
User manual Yes



PNI-HP-6800
Lang Type Name Link
EU10 Declaration of Conformity Declaration of Conformity Link
EU10 User manual User manual Link
