CB radio station PNI Escort HP 6800 ASQ, 12/24 V, MP3 player, USB plug, 4W, AM-FM, cigarette lighter plug included
|
PNI Escort HP 6800 CB Radio StationThe PNI Escort HP 6800 CB radio station is a high-performance device for CB (Citizen Band) communications, ideal for truck drivers, cars, but also for users who want an efficient radio communication solution over medium and long distances. |
Dual power supply 12V/24VThe station can be powered at both 12V and 24V, making it compatible with most cars, trucks, coaches, and other commercial vehicles. |
|
|
SQ (Squelch) and ASQ (Auto Squelch) functionManual SQ (Squelch): Allows the user to manually adjust the signal filter threshold, eliminating unwanted background noise. ASQ (Automatic Squelch): Automatic adjustment to eliminate noise, allowing for clearer reception without constant manual intervention. |
5V/0.5A USB port – Phone charging and MP3 playbackThe station is equipped with a 5V/0.5A USB port, which allows:
|
|
|
Multi-standard – 7 operating rulesThe PNI Escort HP 6800 CB radio station is designed for use in multiple countries by selecting one of the 7 norms (CB standards). By changing the rule, the user can adjust the frequencies, channels and emission limits according to the legislation of the respective country. This feature is useful for drivers who frequently travel abroad, allowing them to use the station in whatever country they are in, in accordance with local regulations. |
Product identification | |
Producer | NIP |
Product code | PNI-HP-6800 |
Product type | CB radio station |
General features | |
Exemplary | Furniture |
Emission band type | AM/FM |
channels | 40 |
Frequency | 26.965 - 27.405 MHz |
Microphone type (pins) | 6 pins |
Speaker audio power | 3W |
Sensitivity (20dB SINAD) | 0.8uV -113 dBm FM / 1.5uV -103 dBm AM |
Audio signal distortion | less than 5% @ 1KHz |
Emission power | 4W |
feeding | 12V / 24V |
Dimensions (W x H x D / Weight) | 140 X 125 X 40 mm / 1,096 |
Special features | |
Channel scan | Yes |
ASQ | Yes |
Manual squelch | Yes |
Accessory connection | 1-pin plug |
Operating temperature | -26°C ~ +80°C |
Emergency function | Yes |
Screen lighting | Yes |
Key illumination | Yes |
Display type | LCD |
Display | Yes |
MP3 Player | Yes |
Rear panel connections | |
Additional speaker connection | Yes |
Front panel connections | |
USB port | Yes |
The package contains | |
Radio station | Yes |
Microphone | Yes |
Radio station mounting bracket and screws | Yes |
Microphone holder and screws | Yes |
Power cable | Yes |
Cigarette lighter socket | Yes |
User manual | Yes |
