CB radio station TTi TCB-550 EVO, DSS, VOX, NB filter, Scan, multicolored screen, 12-24V
Always in EVOLUTIONThe new TTi TCB-550 EVO CB radio station brings several new functions and features compared to the previous model, among which we mention VOX that allows speaking into the microphone without pressing the PTT key, NB filter for a clearer and distortion-free reception, multi-color display and the possibility 12V or 24V power supply. | |
Automatic tuning with automatic DSS squelchThe CB TTi TCB-550 EVO radio station complies with the European standards in force and allows communication on the 40 channels in the 27 MHz band used for info traffic. The station allows you to communicate in both types of bands: AM and FM. It is also equipped with a quick selector of emergency and international infotraffic channels, namely 9-19. . | |
Ergonomic microphone with 4 pinsRadio communication is done in the simplex system with the help of the microphone and speaker: - one speaks and the others listen. By activating the VOX function you can communicate without pressing the PTT key. The microphone is of normal size, easy to handle and is electret type with 4-pin plug. | |
Ready to goYou can use the product in any car as it is one of the smallest CB stations on the market. Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing. The novelty of this model is given by the dual 12-24V power supply. |
Video presentation |
|
CB radio station TTi TCB 550 EVO UK |
Product identification | |
Producer | TT |
Product code | PNI-TCB-550EVO |
Product type | CB radio station |
General characteristics | |
Exemplary | Portable |
Emission band type | AM/FM |
channels | 40 |
Frequency | 26.965 - 27.405 MHz |
Microphone type (pins) | 4 pins |
Speaker audio power | 2W |
Sensitivity (20dB SINAD) | 0.7㎶ for 10dB (S+N)/N in AM mode / 0.7㎶ for 20dB SINAD in FM mode |
Audio signal distortion | less than 8% @ 1KHz |
Emission power | 4 W |
Modulation | FM: 1.8KHz ± 0.2KHz, AM: 85-95% |
EEPROM memory | Yes |
feeding | 12 V / 24 V |
Dimensions (W x H x D / Weight) | 135 X 125 X 35 mm / 767 gr |
Special features | |
Channel scan | Yes |
ASQ | Yes |
Noise filter | NB (Noise Blanker) |
Multicolor screen | Yes, 3 colors |
VOX | Yes |
Manual squelch | Yes |
TOT (Time out Timer) | Yes |
Operating temperature | -10°C ~ +55°C |
Screen lighting | Yes |
Key lighting | Yes |
Rear panel connections | |
Additional speaker connection | Yes |
Bluetooth dongle connection | Yes |
The package contains | |
Radio station | Yes |
Microphone | Yes |
Support and screws for holding the radio station | Yes |
Microphone support and screws | Yes |
Power cord | Yes |
Cigarette lighter plug | Yes |
User manual | Yes |
