CB radio station TTi TCB-900 EVO, DSS, SQ, Dual Watch, Mic Gain, 12V-24V with sticky pad Blue as a gift

CB radio station TTi TCB-900 EVO, DSS, SQ, Dual Watch, Mic Gain, 12V-24V with Blue sticky pad included
£82.94
Availability: In stock
SKU
TTI-PACK77

DSS - Automatic Squelch

The CB TTi TCB-900 EVO radio station product is equipped with an automatic squelch system also called Dynamic Squelch System, extremely performant, which allows a very good filtering of conversations and receptions from CB (Citizen Band)

TTI-TCB-900-DSS

Dual Voltage

TCB-900-EVO-2

An advantage of this product is the dual power supply at both 12 V and 24 V which allows it to be used in both cars and trucks, dump trucks, coaches that have a 24 V electrical installation.

Front Speaker

The TTi TCB-900 EVO radio station is equipped with a front speaker, again an advantage if it will be mounted on the dashboard, or in the front panel of the cab of a truck, truck, or coach. Thus, the sound is heard clearly and loudly, in the direction of the user.

TCB-900-EVO-3

Format 1 DIN

TCB-900-EVO-4

The case format is 1 DIN identical to classic car cassette recorders. This makes it suitable for specially designed spaces, which can be found in cars as well as in trucks, dump trucks and coaches.

Multi-Band

Now radio amateurs can also benefit from the advantages of this product, the TTi TCB-900 radio station having 11 bands usable in Europe and beyond.

TCB-900-EVO-5

VOX function

TCB-900-EVO-8

The VOX function with which this station is equipped allows hands-free communication, the microphone capturing the voice remotely. The function is also accompanied by a very useful sensitivity adjustment in case the distance from the microphone varies.

Special functions

The TTi TCB-900 EVO radio station has, in addition to the classic functions, a series of special functions that can help in the use of the product such as: ATT, Mute, Lock, BL, + a special menu with some additional settings.

TCB-900-EVO-6

Ready to use

TCB-900-EVO-7

The TTi TCB-900 EVO radio station allows immediate use. All you have to do is attach a calibrated antenna to it, connect it to the cigarette lighter socket of the car or directly to the battery and turn it on channel 22. The product comes with a station stand, microphone stand and mounting screws.



Write Your Own Review
You're reviewing:CB radio station TTi TCB-900 EVO, DSS, SQ, Dual Watch, Mic Gain, 12V-24V with sticky pad Blue as a gift
Your Rating
Product identification
Manufacturer TTi
Product Code PNI-TCB-900EVO
Product Type CB radio
General Features
Model Mobile
Band type AM / FM
Channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 6 pin
Audio speaker power 2 W
Sensitivity (20dB SINAD) 0.7㎶ for 10dB (S+N)/N in AM mode / 0.7㎶ for 20dB SINAD in FM mode
Audio signal distortion less than 8% @ 1KHz
Transmit Power 4 W
Power supply 12 V / 24 V
Absorbed current max. 1.6A
Dimensions (W x H x H / Weight) 170 x 90 x 50 mm / 764 gr
Mounting 1DIN Yes
Special Features
Dual Watch Yes
Channel Scan Yes
Mic Gain Yes
ASQ From
Key Lock Yes
LCR - last selected channel Yes
Adjustable ASQ
Emergency channels Yes
Multicolor display Yes
VOX From
Manual Squelch Yes
Accessory connection 1 pin plug
Operating temperature -26°C ~ +80°C
Key sound Yes
PTT (Push To Talk) Yes
Display illumination Yes
Key illumination Yes
Rear panel connections
Additional speaker connection Yes
Bluetooth dongle connection Yes
Package contains
Radio Yes
Microphone Yes
Bracket and screws for radio Yes
Microphone mounting bracket and screws Yes
Power cable Yes
Lighter plug Yes
User manual Yes
1DIN mounting housing



PNI-TCB-900EVO
Lang Type Name Link
EU2 User manual User manual EN, RO Link
RO Declaration of Conformity Declaration of conformity RO Link
