TTi TCB-550 EVO with Extra 45

Kit Radio CB TTi TCB-550 EVO + Antenna PNI Extra 45

TTi TCB-550 EVO with ML145

CB TTi TCB-550 EVO radio station kit + PNI ML145 antenna with magnet

CB TTi TCB-550 EVO radio station package, VOX, Scan, multicolored screen, 12-24V and PNI ML100 antenna with magnet, 100 cm, 26-30MHz, 250W

CB TTi TCB-550 EVO radio station package, VOX, Scan, multicolored screen, 12-24V and PNI ML100 antenna with magnet, 100 cm, 26-30MHz, 250W
£66.72
Availability: In stock
SKU
TTI-PACK59

PNI-TCB-550EVO - CB radio station TTi TCB-550 EVO, DSS, VOX, NB filter, Scan, multicolor screen, 12-24V



Radio station, TTI, VOX, Noise blanker, Scan

Always in EVOLUTION

The new TTi TCB-550 EVO CB radio station brings several new functions and features compared to the previous model, among which we mention VOX that allows speaking into the microphone without pressing the PTT key, NB filter for a clearer and distortion-free reception, multi-color display and the possibility 12V or 24V power supply.

Automatic tuning with automatic DSS squelch

The CB TTi TCB-550 EVO radio station complies with the European standards in force and allows communication on the 40 channels in the 27 MHz band used for info traffic.

The station allows you to communicate in both types of bands: AM and FM. It is also equipped with a quick selector of emergency and international infotraffic channels, namely 9-19.

.

Radio station, TTI, VOX, Noise blanker, Scan

Radio station, TTI, VOX, Noise blanker, Scan

Ergonomic microphone with 4 pins

Radio communication is done in the simplex system with the help of the microphone and speaker:

- one speaks and the others listen.

By activating the VOX function you can communicate without pressing the PTT key.

The microphone is of normal size, easy to handle and is electret type with 4-pin plug.

Ready to go

You can use the product in any car as it is one of the smallest CB stations on the market.

Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing.

The novelty of this model is given by the dual 12-24V power supply.

Radio station, TTI, VOX, Noise blanker, Scan

PNI-ML100 - PNI ML100 CB antenna, length 100 cm, 26-30MHz, 250W, 125mm magnet included



performance CB antenna PNI ML100

CB antenna performance PNI ML100

The performance of the product is closely related to the technical characteristics of the antenna in ideal conditions of installation and use: SWR <= 1.1, maximum power applied 250 W continuously, impedance 50 Ohms, stainless steel, etc.

Communication distance

The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 12 km is achieved under ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.

range of action CB PNI ML100 antenna

CB antenna PNI ML100 with length 100 cm

Antenna length

The length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML100 antenna is 110 cm long (magnetic base included).

Magnetic base

The magnetic base 120/PL in the package is provided with a 4 m cable, enough to place the antenna on the dome, it has a diameter of 125 mm and a strong magnet that gives the antenna stability even at high speeds.

magnetic base DV CB antenna PNI ML100

CB Antenna kit PNI ML100

Complete package

This kit is ready for assembly with: antenna, magnetic base with cable and plug PL259, Allen key for calibration. All you have to do is mount the antenna on the magnetic base, connect it to a CB radio station and calibrate it to use it at maximum performance.

Write Your Own Review
You're reviewing:CB TTi TCB-550 EVO radio station package, VOX, Scan, multicolored screen, 12-24V and PNI ML100 antenna with magnet, 100 cm, 26-30MHz, 250W
Your Rating

PNI-TCB-550EVO - CB radio station TTi TCB-550 EVO, DSS, VOX, NB filter, Scan, multicolor screen, 12-24V

Product identification
Producer TT
Product code PNI-TCB-550EVO
Product type CB radio station
General characteristics
Exemplary Portable
Emission band type AM/FM
channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 4 pins
Speaker audio power 2W
Sensitivity (20dB SINAD) 0.7㎶ for 10dB (S+N)/N in AM mode / 0.7㎶ for 20dB SINAD in FM mode
Audio signal distortion less than 8% @ 1KHz
Emission power 4 W
Modulation FM: 1.8KHz ± 0.2KHz, AM: 85-95%
EEPROM memory Yes
feeding 12 V / 24 V
Dimensions (W x H x D / Weight) 135 X 125 X 35 mm / 767 gr
Special features
Channel scan Yes
ASQ Yes
Noise filter NB (Noise Blanker)
Multicolor screen Yes, 3 colors
VOX Yes
Manual squelch Yes
TOT (Time out Timer) Yes
Operating temperature -10°C ~ +55°C
Screen lighting Yes
Key lighting Yes
Rear panel connections
Additional speaker connection Yes
Bluetooth dongle connection Yes
The package contains
Radio station Yes
Microphone Yes
Support and screws for holding the radio station Yes
Microphone support and screws Yes
Power cord Yes
Cigarette lighter plug Yes
User manual Yes


PNI-ML100 - PNI ML100 CB antenna, length 100 cm, 26-30MHz, 250W, 125mm magnet included

Product identification
Product code PNI-ML100
Work tape ? B
Product color (spike) Silver
General characteristics
Working frequency 26 - 28 Mhz
Number of channels 90
Maximum power applied 250W
Minimum SWR in the center of the band 1.0
Length 100 cm (110 cm with base included)
Impedance 50 Ohms
Material Stainless steel
Connector type PL
Hole diameter 16 mm
Cable length 4 m
Weight 1.2 Kg
size 1000 x 150 x 40 mm
Gain 4 dBi
Working distance 12 km
Operating temperature -26°C ~ +80°C
The package contains
Radio station antenna Yes
RG58 cable 4 m
Plug PL259 Yes
Magnetic base 125 mm
