CB TTi TCB-550 N radio station with automatic squelch
Maximum power 4WOne of the most popular CB radio stations, it excels through its small size, ease of use and very good performance both on reception and on transmission in info traffic channels and not only. The CB TTi TCB-550 radio station complies with the legislation in force according to European standards, having the maximum legal power allowed of 4 W. | |
Automatic tuning with automatic DSS squelchThe CB TTi TCB-550 radio station complies with the European standards in force and allows communication on the 40 channels in the 27 MHz band used for info traffic. The station allows you to communicate in both types of bands: AM and FM. It is also equipped with a quick selector of emergency and international infotraffic channels, namely 9-19. | |
Ergonomic microphone with 4 pinsRadio communication is done in the simplex system with the help of the microphone and speaker: - one speaks and the others listen. The microphone is full size, easy to handle and electret type with 4 pin plug. | |
Ready to goYou can use the product in any car as it is one of the smallest CB stations on the market. Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing. |
Video presentation |
|
TTi TCB 550 N radio station with automatic squelch |
Product identification | |
Product code | TCB-550 |
General characteristics | |
Frequency | 26.965-27.405 MHz |
Emission band type | AM-FM |
channels | 40 |
feeding | 12 V |
Dimensions (W x H x D / Weight) | 124 x 37 x 136 mm / 0.65 kg |
Microphone type (pins) | 4 pins |
Sensitivity (20dB SINAD) | less than 1 µV (AM/FM) |
Speaker audio power | 2W |
Audio signal distortion | less than 8% @ 1 KHz |
Emission power | 4W |
Modulation | FM: 1.8KHz ± 0.2KHz, AM: 85-95% |
Absorbed current | maximum 1.6A |
Exemplary | Portable |
Special features | |
Channel scan | Yes |
RF Gain | |
Small Gain | |
ASQ - Automatic Squelch | Yes |
Keyboard lock | Yes |
Emergency channel button 9/19 | Yes |
ALL - Time out Timer | Yes |
Rear panel connections | |
Additional speaker connection | Yes |
The package contains | |
Radio station microphone | Yes |
Radio station | Yes |
Microphone holder | Yes |
Station mounting support | Yes |
Power cord | Yes |
Lighter plug | Yes |
Manual in Romanian | Yes |
TCB-550 |
|
