TTI TCB-900

CB TTi TCB-900 12-24V power station with front speaker, AM-FM, 12V-24V, 4W, Scan, ASQ, Lock

CB TTi TCB-550 N radio station with automatic squelch

The TCB-550 is one of the most sought after CB radio stations with automatic squelch, the included lighter jack being at the same time a CB station with the best value for money. The last batch has orange screen lighting.
£42.25
Availability: In stock
SKU
TCB-550

Radio station CB, TTI, CB, PNI, Auto

Maximum power 4W

One of the most popular CB radio stations, it excels through its small size, ease of use and very good performance both on reception and on transmission in info traffic channels and not only.

The CB TTi TCB-550 radio station complies with the legislation in force according to European standards, having the maximum legal power allowed of 4 W.

Automatic tuning with automatic DSS squelch

The CB TTi TCB-550 radio station complies with the European standards in force and allows communication on the 40 channels in the 27 MHz band used for info traffic.

The station allows you to communicate in both types of bands: AM and FM. It is also equipped with a quick selector of emergency and international infotraffic channels, namely 9-19.

Radio station CB, TTI, CB, PNI, Auto

image description

Ergonomic microphone with 4 pins

Radio communication is done in the simplex system with the help of the microphone and speaker:

- one speaks and the others listen.

The microphone is full size, easy to handle and electret type with 4 pin plug.

Ready to go

You can use the product in any car as it is one of the smallest CB stations on the market.

Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing.

Radio station CB, TTI, CB, PNI, Auto

Video presentation

TTi TCB 550 N radio station with automatic squelch

Write Your Own Review
You're reviewing:CB TTi TCB-550 N radio station with automatic squelch
Your Rating
Product identification
Product code TCB-550
General characteristics
Frequency 26.965-27.405 MHz
Emission band type AM-FM
channels 40
feeding 12 V
Dimensions (W x H x D / Weight) 124 x 37 x 136 mm / 0.65 kg
Microphone type (pins) 4 pins
Sensitivity (20dB SINAD) less than 1 µV (AM/FM)
Speaker audio power 2W
Audio signal distortion less than 8% @ 1 KHz
Emission power 4W
Modulation FM: 1.8KHz ± 0.2KHz, AM: 85-95%
Absorbed current maximum 1.6A
Exemplary Portable
Special features
Channel scan Yes
RF Gain
Small Gain
ASQ - Automatic Squelch Yes
Keyboard lock Yes
Emergency channel button 9/19 Yes
ALL - Time out Timer Yes
Rear panel connections
Additional speaker connection Yes
The package contains
Radio station microphone Yes
Radio station Yes
Microphone holder Yes
Station mounting support Yes
Power cord Yes
Lighter plug Yes
Manual in Romanian Yes



TCB-550
Lang Type Name Link
BG User manual Manual in lb. Bulgara pentru statia TTi TCB-550 Link
EU Declaration of Conformity Declaratie de conformitate EN, ES, HU, IT, PL, RO Link
EU User manual User manual EN, ES, DE, HU, NL, RO, PL Link
FR User manual Manual de utilizare FR Link
IT User manual Manuale dell'utente IT Link
RO Declaration of Conformity Declaratie de conformitate si certificat de garantie Link
