CB TTi TCB-900 EVO radio station kit + PNI Extra 45 CB antenna with magnet
PNI-TCB-900EVO - CB radio station TTi TCB-900 EVO, DSS, SQ, Dual Watch, Mic Gain, 12V-24V, Bluetooth dongle connector
DSS - Automatic Squelch | |
The CB TTi TCB-900 EVO radio station product is equipped with an automatic squelch system, also known as the extremely high-performance Dynamic Squelch System, which allows a very good filtering of conversations and receptions from CB (Citizen Band) | |
Dual Voltage | |
An advantage of this product is the dual power supply at both 12 V and 24 V, which allows the use in both cars and trucks, dump trucks, coaches that have a 24 V electrical installation. | |
Front speaker | |
The TTi TCB-900 EVO radio station is equipped with a front speaker, again an advantage if it will be mounted on the dashboard, or in the front panel of the cabin of a truck, trailer, or bus. Thus, the sound is heard clearly and strongly, in the direction of the user. | |
1 DIN format | |
The case format is 1 DIN, identical to classic car cassette players. Thus, it fits in the specially designed slots for them, which can be found both in passenger cars, as well as in trucks, dump trucks and coaches. | |
Multi-Band | |
Now radio amateurs can also benefit from the advantages of this product, the TTi TCB-900 radio station having 11 bands usable in Europe and beyond. | |
VOX function | |
The VOX function with which this station is equipped allows hands-free communication with the microphone capturing the voice from a distance. The function is also accompanied by a very useful sensitivity adjustment in case the distance to the microphone varies. | |
Special functions | |
The TTi TCB-900 EVO radio station has, in addition to the classic functions, a series of special functions that can help in using the product, such as: ATT, Mute, Lock, BL, + a special menu with some additional settings. | |
Ready to use | |
The TTi TCB-900 EVO radio station allows immediate use. All you have to do is attach a calibrated antenna to it, connect it to the car cigarette lighter socket or directly to the battery and turn it on on channel 22. The product comes with a station support, microphone support and mounting screws. |
PNI-EXTRA45 - PNI Extra 45 CB antenna, with magnet included, length 45 cm, SWR 1.0, 26-30MHz, 150W, fiberglass
Discreet and efficientThe PNI Extra 45 antenna is the smallest CB antenna (it has a height of only 45 cm) that can be mounted both on cars and on vans or minibuses. Its small dimensions make it almost imperceptible, easily confusing with the radio antenna. | |
Easy installation and calibrationThe PNI Extra 45 antenna is easy to mount, by simply screwing the spike on the magnet fixed on the car dome, but also to calibrate, by rotating the tip with the screw, until the desired performance is obtained. It is recommended that the adjustment/calibration of the antenna be performed by specialized personnel with related equipment. | |
Aerodynamic designThe PNI Extra 45 antenna has a special aerodynamic design that allows the air to slide around the spike, eliminating the noise produced by the wind. |
Product identification | |
Producer | TT |
Product code | PNI-TCB-900EVO |
Product type | CB radio station |
General characteristics | |
Exemplary | Portable |
Emission band type | AM/FM |
channels | 40 |
Frequency | 26.965 - 27.405 MHz |
Microphone type (pins) | 6 pins |
Speaker audio power | 2W |
Sensitivity (20dB SINAD) | 0.7㎶ for 10dB (S+N)/N in AM mode / 0.7㎶ for 20dB SINAD in FM mode |
Audio signal distortion | less than 8% @ 1KHz |
Emission power | 4 W |
feeding | 12 V / 24 V |
Absorbed current | max. 1.6A |
Dimensions (W x H x D / Weight) | 170 x 90 x 50 mm / 764 gr |
1DIN assembly | Yes |
Special features | |
Dual Watch | Yes |
Channel scan | Yes |
Small Gain | Yes |
ASQ | Yes |
Lock the keyboard | Yes |
LCR - the last selected channel | Yes |
ASQ adjustable | |
Emergency channels | Yes |
Multicolor screen | Yes |
VOX | Yes |
Manual squelch | Yes |
Accessory connection | 1 pin plug |
Operating temperature | -26°C ~ +80°C |
Key sound | Yes |
PTT (Push To Talk) | Yes |
Screen lighting | Yes |
Key lighting | Yes |
Rear panel connections | |
Additional speaker connection | Yes |
Bluetooth dongle connection | Yes |
The package contains | |
Radio station | Yes |
Microphone | Yes |
Support and screws for holding the radio station | Yes |
Microphone support and screws | Yes |
Power cord | Yes |
Cigarette lighter plug | Yes |
User manual | Yes |
1DIN mounting case |
