Folding CB PNI LED 1000 antenna, 80 cm long, with cable and butterfly fixed mount, 26-30 MHz, 300 Watt, illuminates during transmission

Be the first to review this product

CB antenna with cable and fixed mounting mount, with LED light.

£21.07

Availability: In stock

SKU

PNI-LED1000

Details

Foldable CB PNI LED 1000 antenna

LED coil

The CB antenna PNI LED 1000 is the continuation of a new line of CB antennas, designed to make the use of the CB band unique. The antenna guarantees superior communication performance and improves visibility to the maximum.

The antenna coil is equipped with diodes that emit light when they are crossed by radio frequency. The coil lights up automatically when the radio emits, thus indicating the correct operation of the equipment. The higher the emission power, the higher the luminous intensity of the LEDs.

Length 80 cm

The CB antenna PNI LED 1000 with a length of 80 centimeters helps the emission and reception in the CB band at a distance of up to 10 km (in ideal conditions, without obstacles).

Factors influencing communication distance:
» Antenna length : longer antennas will have a greater range than shorter antennas.
» Mounting location : the higher the antenna is mounted, the better the range.
» Installation quality : installation mistakes, such as the lack of mass, will lead to a high SWR value and a limited range.
» The surrounding relief : The surrounding relief plays a huge role in determining the range of action. Obstacles, such as buildings or wooded areas will limit the range of action.

Foldable CB PNI LED 1000 antenna

Cable and mount for fixed attachment included

Thanks to the included accessories (butterfly type mount, RG58 cable and PL259 plug), mounting the antenna becomes a simple and fast thing:

» Connect the antenna to a separately purchased fixed support (for example: PNI SPA100 , PNI SPA110 , PNI L1 ) previously mounted on the car.
» Test the SWR in an open area using a reflectometer. In some cases it may be necessary to raise or shorten the wire to obtain an optimal SWR value. For optimal results, we recommend that this procedure, called calibration , be performed by authorized personnel with special equipment. Note: the PNI antennas are calibrated from the factory on the frequency 27.225Mhz (channel 22) .
» Connect the PL259 plug at the end of the antenna cable to the antenna plug on the back of the station.

Video presentation
PNI LED 1000 Foldable CB Antenna 100 cm Long UK

Reviews

Technical specifications

Product identification
Product code	PNI-LED1000
Work tape	? B
Product color (spike)	Silver
Coil color	Black
General characteristics
Working frequency	26 - 30 MHz
Maximum power applied	300W
Minimum SWR in the center of the band	less than 1.2
Length	81 cm
Impedance	50 Ohms
Material	Stainless steel
Cable length	4 m
Working distance	12 km
Operating temperature	-26°C ~ +80°C
tiltable	Yes, up to 90 degrees
The package contains
Radio station antenna	Yes
RG58 cable	Yes
Plug PL259	Yes
Fixed mount	Yes

Download

PNI-LED1000

Lang	Type	Name	Link
EU10	Declaration of Conformity	Declaration of conformity EU10	Link
EU10	User manual	Datasheet EU10	Link
