Kit CB CBI PNC ESCORT CB 8000L ASQ + CB PNI Extra 40 magnet antenna

Be the first to review this product

CB radio station kit and magnetic base antenna.

£59.46

Availability: In stock

SKU

PNI-PACK28

Details

	ASQ Adjustable An innovation in the CB segment, the adjustable automatic squelch (ASQ), offers maximum comfort even for the most demanding users of car CB radio stations. If until now we were used to activating/deactivating the ASQ, now PNI brings its adjustment function, a function that allows the elimination of up to 100% of interference, background noise and jamming in the CB band.
ASQ button on microphone For increased comfort behind the wheel, PNI has positioned the automatic squelch (ASQ) activation/deactivation button on the microphone. In addition to this button, we also find up/down buttons on the microphone for changing channels, so you won't have to take your eyes off the road to operate these main functions.
	Reduced dimensions You can use the product in any car, because it is one of the smallest CB stations on the market. Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing.
Key lock switch The PNI Escort HP 8000L CB radio station has a switch on the front panel that allows the selection of the emergency channel (19), the normal operating mode (CH) and the activation of the key lock function (L) , a useful function in situations where you want to avoid touching accidental pressing of the station keys.

CB antenna PNI Extra 45 with magnet included SWR 1.0

Discreet and efficient

The PNI Extra 40 antenna is the smallest CB antenna (it has a height of only 44 cm - base included) that can be mounted both on cars and on vans or minibuses. Its small dimensions make it almost imperceptible, easily confusing with the radio antenna. The average reception distance is 7 km.

Easy installation and calibration

The PNI Extra 40 antenna is easy to mount, by simply screwing the spike on the magnet fixed on the car dome, but also to calibrate, by turning the screw on the spike, until the desired performance is obtained. It is recommended that the adjustment/calibration of the antenna be performed by specialized personnel.

CB antenna PNI Extra 40 with magnet included SWR 1.0

Antenna performance

The PNI Extra 40 antenna has the characteristics of a large antenna: SWR 1.2:1, impedance 50 Ohms, frequency 26.8 - 27.6 MHz.

Video presentation

CB PNI Escort HP 8000L

The PNI Extra 40 antenna

Reviews

Technical specifications

Product identification
Product code	PNI-PACK28
General characteristics of the radio station
Model	Portable
Emission band type	AM-FM
Frequency	26.965-27.405 MHz
channels	40 AM/FM
Microphone type	6 pins
Audio signal distortion	less than 8% @ 1 KHz
Emission power	4 W
Modulation	FM: 3KHz ± 0.2KHz, AM: 85-90%
feeding	12 V
Consumption	second
Dimensions / Weight	115 x 36 x 152 mm / 0.8 kg
Special radio station features
ASQ (automatic squelch)	Yes
Lock the keyboard	Yes
Emergency channel button 9/19	Yes
Adjustable ASQ	Yes
Characteristics of the radio antenna
Working frequency	26.8 - 27.6 MHz
Maximum power applied	30W
Minimum SWR in the center of the band	less than 1.2:1
Antenna length	44 cm (base included)
Working distance	7 km
Impedance	50 Ohms
Material	Fiber glass
Connector type	PL259
Magnetic base included	Yes
Magnetic base diameter	90 mm
Cable length	4 m
The package contains
CB radio station	Yes
CB radio antenna	Yes
Magnetic base	Yes

Download

PNI-HP8000L

Lang	Type	Name	Link
EU	Declaration of Conformity	Declaratie de conformitate EN, BG, DE, ES, FR, HU, IT, PL, RO	Link
EU10	Declaration of Conformity	Declaration of conformity EU9	Link
EU10	User manual	User manual EU10	Link
RO	Declaration of Conformity	DC&CG	Link
