Kit CB radio CBI ESCORT HP 8000L ASQ + CB PNI ML100 antenna
ASQ AdjustableAn innovation in the CB segment, the adjustable automatic squelch (ASQ), offers maximum comfort even for the most demanding users of car CB radio stations. If until now we were used to activating/deactivating the ASQ, now PNI brings its adjustment function, a function that allows the elimination of up to 100% of interference, background noise and jamming in the CB band. | |
ASQ button on microphoneFor increased comfort behind the wheel, PNI has positioned the automatic squelch (ASQ) activation/deactivation button on the microphone. In addition to this button, we also find up/down buttons on the microphone for changing channels, so you won't have to take your eyes off the road to operate these main functions. | |
Reduced dimensionsYou can use the product in any car, because it is one of the smallest CB stations on the market. Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being uncomfortable or disturbing. | |
Key lock switchThe PNI Escort HP 8000L CB radio station has a switch on the front panel that allows the selection of the emergency channel (19), the normal mode of operation (CH) and the activation of the key lock function (L) , a useful function in situations where you want to avoid touching accidental pressing of the station keys. |
CB antenna performance PNI ML100The performance of the product is closely related to the technical characteristics of the antenna in ideal installation and use conditions: SWR <= 1.0, maximum power applied 400 W, impedance 50 Ohms, stainless steel, etc. | |
Communication distanceThe communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 12 km is achieved under ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance. | |
Antenna lengthThe length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML100 antenna is 110 cm long (magnetic base included). | |
Magnetic baseThe magnetic base 120/PL in the package is provided with a 4 m cable, enough to place the antenna on the dome, it has a diameter of 125 mm and a strong magnet that gives the antenna stability even at high speeds. | |
Complete packageThis kit is ready for assembly with: antenna, magnetic base with cable and plug PL259, Allen key for calibration. All you have to do is mount the antenna on the magnetic base, connect it to a CB radio station and calibrate it to use it at maximum performance. |
Video presentation |
|
CB PNI ML100 antenna ENCB PNI Escort HP 8000L |
Product identification | |
Product code | PNI-PACK30 |
General characteristics of the radio station | |
Model | Portable |
Emission band type | AM-FM |
Frequency | 26.965-27.405 MHz |
channels | 40 AM/FM |
Microphone type | 6 pins |
Audio signal distortion | less than 8% @ 1 KHz |
Emission power | 4 W |
Modulation | FM: 3KHz ± 0.2KHz, AM: 85-90% |
feeding | 12 V |
Consumption | second |
Dimensions / Weight | 115 x 36 x 152 mm / 0.8 kg |
Special radio station features | |
ASQ (automatic squelch) | Yes |
Lock the keyboard | Yes |
Emergency channel button 9/19 | Yes |
Adjustable ASQ | Yes |
Characteristics of the radio antenna | |
Working frequency | 26 - 28 Mhz |
Number of channels | 100 |
Maximum power applied | 400 W |
Minimum SWR in the center of the band | 1.0 |
Antenna length | 100 cm (110 cm with base included) |
Impedance | 50 Ohms |
Material | Stainless steel |
Connector type | PL259 |
Hole diameter | 16 mm |
Magnetic base included | Yes |
Magnetic base diameter | 125 mm |
Cable length | 4 m |
The package contains | |
CB radio station | Yes |
CB radio antenna | Yes |
Magnetic base | Yes |
PNI-HP8000L |
| ||||||||||||
PNI-ML100 |
|
