LEMM Vortex 3000 PL CB antenna, 200 cm, 26.2-27.8Mhz, 2500W, without cable, made in Italy

LEMM Vortex 3000 PL CB antenna, 200 cm, 26.2-27.8Mhz, 2500W, without cable, made in Italy
£154.51
Availability: In stock
SKU
PNI-AT-3000V

LEMM Vortex 3000 PL CB antenna

Length 200 cm

The CB antenna LEMM Vortex 3000 PL with a length of 200 centimeters helps the emission and reception in the CB band at a distance of up to 15-20 km (under ideal conditions, without obstacles).

Factors influencing communication distance:

  • antenna length: longer antennas will have a greater range than shorter antennas,
  • mounting location: the higher the antenna is mounted, the better the range,
  • installation quality: installation mistakes such as lack of grounding will result in high SWR and limited range.
  • Terrain: The surrounding terrain plays a huge role in determining range. Obstacles such as buildings or wooded areas will limit the range.

PL type connector

The LEMM Vortex 3000 PL has a PL threaded mount. The antenna can be fixed using a magnetic base (eg PNI 145/PL 145mm), a fixed support and a connecting cable (eg PNI T601).

  • connect the antenna to the attachment.
  • test the SWR in an open area using a reflectometer. In some cases it may be necessary to raise or shorten the wire to obtain an optimal SWR value.
  • connect the PL259 jack on the end of the antenna cable to the antenna jack on the back of the station.

LEMM Vortex 3000 PL CB antenna

LEMM Vortex 3000 PL CB antenna

Made in Italy

LEMM antennas are manufactured in Italy with Italian machinery and rigorously assembled by hand . This allows maximum control over the quality of LEMM products.

Write Your Own Review
You're reviewing:LEMM Vortex 3000 PL CB antenna, 200 cm, 26.2-27.8Mhz, 2500W, without cable, made in Italy
Your Rating
Product identification
Product code PNI-AT-3000V
Work tape ? B
Product color (spike) Silver
Coil color Black
General characteristics
Working frequency 26.2 - 27.8 MHz
Number of channels 120
Maximum power applied 2500W
Minimum SWR in the center of the band 1.0-1.1
Length 200 cm
Impedance 50 Ohms
Material Stainless steel
Connector type PL
Hole diameter 16 mm
Weight 700 gr
size 2000 x 50 x 50 mm
Gain >5 dBi
Polarization vertically
Working distance 20 km
Magnetic base It is not included
Operating temperature -26 ~ +55°C
The package contains
Radio station antenna Yes
