NVR PNI House 3316H4 with IP 16CH POE 12MP, 4K output, Network Bandwidth 192Mbps/192Mbps, 2 x HDMI, 2 x LAN Gigabit, SATA x 4, E-SATA x 1

Support 16CH 12MP/9MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/ 720P/960H/D1/CIF Input IPC cameras
H.265S/H.265+/H.265/H.264
Intuitive and easy-to-use graphical user interface (GUI), Windows operating system style with mouse
Multi-type recording: manual / timed / motion / sensor / POS / AI recording
Playback: 16-channel simultaneous playback
Search: time range, time, event, tag and smart search
Supports face detection and comparison (only with compatible cameras)
Support for VCA (Video Content Analytics) events such as abandoned/missing object, region intrusion, tripwire, video exception, etc.
Supports license plate recognition (only with compatible cameras)
Supports overlay of POS information when viewing live and playing records
Pentaplex: preview, record, playback, backup and remote access
Network protocol DHCP, DDNS, PPPoE
Compatible with third-party IPC cameras such as ONVIF, Hikvision, etc.
Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration
Support 16CH PoE IPC direct connection to NVR through PoE ports
Multi-user online simultaneously
Manage authorizations, view log and view device status
4K output, real high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
It supports NAT function and QRC code scanning on mobile phones
Powerful mobile surveillance via iOS and Android smartphones

Product identification
Product code	PNI-3316H4-S
Producer	PNI
General characteristics
Number of video channels	16 POE channels
View on mobile and PC	Android, iOS, Windows
Video compression	H.265S/H.265+/H.265/H.264
Audio compression	G.711U G.711A G.726
Frames per second (max FPS)	12MP: 20fps; 9MP or lower resolution: NTSC: 30fps; PAL: 25fps
Recording resolution and number of channels	16 CH POE: 12MP / 9MP/8MP / 6MP /5MP / 4MP / 3MP / 1080P / 1280x1024 / 960P / 720P
Playback resolution	Max. 4K
Output resolution	HDMI1 : 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768 HDMI2 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA ×1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA and HDMI1 output the same video source
Storage capacity	maximum 4 x 10 TB HDD (not included) dedicated to video surveillance
Network interface	RJ 45 1000 Mbps × 2
Audio inputs	16 CH IPC audio input
Audio output	1 x RCA
Video inputs	16 x RJ45 POE
Video output	2 x HDMI, 1 x VGA
Alarm Input/Output	16 alarm inputs 4 alarm outputs
Communication interface	1 x RS485
USB interface	USB 3.0 × 1; USB 2.0 × 2
PTZ control	Yes, RS485
Registration type	Dual stream
Supply voltage	230V AC
Consumption	20W (without HDD)
size	440 X 405 X 79 mm
Weight	4859 g
Human face detection	Yes
Human form detection	Yes
The package contains
DVR	Yes
Mouse	Yes
Power	Yes
Mains power cable
User manual	Yes
Software CD	Yes
SATA cable	Yes, 4 pieces
