CB PNI Escort HP 5500 radio station kit

CB PNI Escort HP 5500 radio station kit with CB PNI LED 2000 antenna, 90 cm, 500W, illuminates during transmission, magnetic base included

PNI Escort HP 5500 CB radio station

Kit PNI Escort HP 5500 CB radio station with CB PNI ML29 antenna, 34 cm, with magnetic base, black

PNI Escort HP 5500 CB radio station and CB PNI ML100 antenna, length 100 cm, with magnetic base included

PNI Escort HP 5500 CB radio station and CB PNI ML100 antenna, length 100 cm, with magnetic base included
£62.21
Availability: In stock
SKU
PNI-PACK125

PNI-HP5500 - CB radio PNI Escort HP 5500, multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, cigarette lighter plug included



statie radio cb, microfon, PNI

Simplicity for everyone

The PNI Escort HP 5500 CB PNI Escort CB radio is ultra compact, measuring only 115 X 115 X 35 mm it can fit into even the smallest spaces.

Easy to install: just plug it into the cigarette lighter socket and connect it to the outdoor CB antenna mounted on the car's dome.

ThePNI Escort HP 5500 has been designed with simplicity in mind, so anyone can use it with ease. The high-quality electret condenser encapsulated in the microphone delivers clear, powerful sound.

Important features - anti-noise: SQ, ASQ and RF Gain

The PNI Escort HP 5500 CB PNI Escort CB radio gives you the best possible control over CB band-specific background noise.

The analog adjustableSQ function with potentiometer and the 5-level ASQ allow the user to filter and eliminate noise making communication clearer.

The 7-levelRF Gain function allows control over the receive frequency, reducing distortion.

Other features of the PNI Escort HP 5500 PNI Escort HP 5500: 4W transmit power, 12-24V power supply, 40 channels, AM/FM modulation, 9-19 emergency channels, 6-pin microphone connector, additional external speaker jack.

statie radio cb, microfon, PNI

statie radio cb, microfon, PNI

Multi-standard and multi-band CB station

By setting the standard and modulation, you can use the station in the United Kingdom (UK) and most European Union countries.

PNI Escort HP 5500 is equipped with the main European bands(EU, CE, UK, PL, dE, in, i0, l2).

NOTE, to change the norm:

1. Turn off the station; simultaneously press the PTT key + the UP key on the microphone while restarting the radio station

2. The LED corresponding to the A/F key lights and the current norm appears on the display

3. Press the SUS-JOS keys to reach the desired norm, then restart the station or press the PTT key to exit norm setting mode.

PNI-ML100 - PNI ML100 CB Antenna PNI ML100, 100cm length, 26-30MHz, 250W, 125mm magnet included



performante Antena CB PNI ML100

PNI ML100 CB antenna performance

The performance of the product is closely related to the technical characteristics that the antenna has in ideal conditions of mounting and use: SWR <= 1.1, maximum applied power 250 W continuous, impedance 50 Ohms, stainless steel etc.

Communication distance

Communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of maximum 12 km is reached under ideal working conditions: calibrated antenna, open field without obstacles, station with maximum legal admissible power of 4W and standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.

raza de actiune Antena CB PNI ML100

Antena CB PNI ML100 cu lungime 100 cm

Antenna length

Antenna length is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range. The PNI ML100 antenna is 110 cm long (magnetic base included).

Magnetic base

The magnetic base 120/PL in the package comes with a 4 m cable, sufficient for placing the antenna on the dome, has a diameter of 125 mm and a strong magnet which gives the antenna stability even at high speeds.

baza magnetica DV Antena CB PNI ML100

kit Antena CB PNI ML100

Complete package

This kit is ready to install and includes: antenna, magnetic base with cable and PL259 plug, and a calibration probe. All you need to do is to mount the antenna on the magnetic base, connect it to a CB radio station and calibrate it to use it at maximum performance.

Write Your Own Review
You're reviewing:PNI Escort HP 5500 CB radio station and CB PNI ML100 antenna, length 100 cm, with magnetic base included
Your Rating

PNI-HP5500 - CB radio station PNI Escort HP 5500, multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, cigarette lighter plug included

Product identification
Producer NIP
Product code PNI-HP5500
Product type CB radio station
General features
Exemplary Furniture
Emission band type AM/FM
channels 40
Frequency 26.965 - 27.405 MHz
Microphone type (pins) 6 pins
Speaker audio power 3W
Sensitivity (20dB SINAD) FM -120 dBm, AM -118 dBm@ SINAD 12dB
Audio signal distortion less than 5% @ 1KHz
Emission power 4W
Modulation FM: 2KHz, AM: 80%
EEPROM memory Yes
feeding 12V / 24V
Dimensions (W x H x D / Weight) 115 X 115 X 35 mm / 611 g
Special features
RF Gain Yes
ASQ Yes, 5 levels
Adjustable ASQ Yes
Emergency channels Yes
Automatic digital squelch (ASQ) Yes
Manual squelch Yes
Accessory connection 1-pin plug
Operating temperature -26°C ~ +80°C
Screen lighting
Display type LCD
Rear panel connections
Additional speaker connection Yes
The package contains
Radio station Yes
Microphone Yes
Radio station mounting bracket and screws Yes
Microphone holder and screws Yes
Power cable Yes
Cigarette lighter socket Yes
User manual Yes


PNI-ML100 - PNI ML100 CB antenna, length 100 cm, 26-30MHz, 250W, 125mm magnet included

Product identification
Product code PNI-ML100
Workband ? B
Product color (spike) Silver
General features
Working frequency 26 - 28 MHz
Number of channels 90
Maximum applied power 250W
Minimum SWR in the center of the band 1.0
Length 100 cm (110 cm with base included)
Impedance 50 Ohms
Material Stainless steel
Connector type PL
Hole diameter 16 mm
Cable length 4m
Weight 1.2 Kg
size 1000 x 150 x 40 mm
Gain 4 dBi
Working distance 12 km
Operating temperature -26°C ~ +80°C
The package contains
Radio station antenna Yes
RG58 cable 4m
PL259 plug Yes
Magnetic base 125mm



PNI-ML100
Lang Type Name Link
EU10 Declaration of Conformity Declaration of conformity EU10 Link
EU10 User manual User manual EU10 Link
