PNI IP1MP 720p video surveillance camera with 2.8

Access and control methods

The PNI IP1MP camera can be controlled from mobile devices through the vMEyeCloud application compatible with Android and iOS, and from the PC through the General CMS software. The CMS installation file can be found on the CD included in the package or you can download it from our website, from the product page, Download section.

Kit supraveghere video PNI House IPMAX2

Varifocal lenses

The PNI IP1MP video camera is equipped with 2.8 - 12 mm varifocal lenses that allow you to set the zoom and focus to the desired points.

Camera cu IP PNI IP1MP varifocala de exterior 720p

P2P function and HD resolution

The PNI IP1MP IP camera can be accessed directly via P2P connection, without the need to configure the router. By entering your username and password you have easy access to all the functions of the camera.

Visualization even in low light conditions

The PNI IP1MP IP camera is equipped with 42 infrared LEDs, which allows you to view even at night, at a distance of up to 50 m. It can be used for surveillance of your home, offices, factories, shops, hospitals, etc. Simple, convenient and in real time.

Camera cu IP PNI IP1MP varifocala de exterior 720p

Remote control

You can monitor and control your camera from any internet browser (Internet Explorer, Chrome, Firefox, Safari) or with the help of dedicated software for Windows, Android or iOS, from anywhere in the world.

Remote recording on PC or NVR

You can record the images taken by the video camera on a computer, over the Internet (provided that it is turned on for the entire duration of the recording) or on an NVR (provided that it has installed at least one HDD set to read-write mode).

Camera cu IP PNI IP1MP varifocala de exterior 720p

Camera cu IP PNI IP1MP varifocala

Outdoor and indoor

You can use the product for surveillance of indoor and outdoor spaces. The IP66 protection class guarantees the insulation of the internal components of the chamber from moisture and dust.

Compatible feeder

If you use the camera in stand-alone mode, we recommend using a compatible 12V 2 A power supply or the PNI model 220V - 12V 5A power supply for surveillance cameras and DVR.

Alimentator CCTV

Video presentation
The PNI IP1MP camera

Reviews

Technical specifications

Product identification
Product code	PNI-IP1MPXV
Color	Gray
Image sensor
Image sensor	CMOS
Sensor resolution	1MP
Resolution	720P
Lens type	Varifocal 2.8 - 12 mm
Viewing angle	86°
Video
Resolutions	720P (1280x720)
Network
Ethernet	Yes, 10/100Mbps RJ-45
Supported protocols	ONVIF 2.4
General features
Infrared illumination	42 LEDs
size	273 x 90 x 92 mm
Net weight	696g
Motion detection	Yes
IR distance	up to 50 m
Dedicated application	XMeye
feeding
Supply voltage	12V / 2A
The package contains
Chamber	Yes
Fixing bracket	Yes
Software CD	Yes
User manual	Yes
Operating parameters
fitting	Outside
Protection class	IP66
Operating temperature	-20 ~ +40°C
Operating humidity	less than 95%

Download

PNI-IP1MPXV

Lang	Type	Name	Link
EU	User manual	Manual utilizare RO, EN, HU	Link
HU	Declaration of Conformity	Garancialevél & Minöségi nyilatkozat	Link
HU	User manual	Használati útmutató IP kamera	Link
RO	Software	CD Software	Link
RO	Declaration of Conformity	DC&CG	Link
RO	User manual	Manual software CMS	Link
