PNI IP6424 video surveillance camera, 8MP, D-WDR, Digital Zoom, with intelligent detection or identification functions, 180 degree panoramic view, 12V, POE, IP67

Write Your Own Review

Product identification
Producer	PNI
Product code	PNI-IP6424-S
Color	White
Image sensor
Image sensor	1/1.8" CMOS
Sensor resolution	8MP
Resolution	3840x2160
Lens type	3.0 mm x 4
Minimal lighting	Color: 0.008Lux@(F2.0 AGC ON); B/W: 0.008Lux @(F2.0 AGC ON);0Lux with IR
Viewing angle	180°
IR-Cut filter	Yes
Video
Image compression	Smart H.265/H.264/MJPEG
Flip/mirror image	Vertically/horizontally
Video frequency	50 Hz, 60 Hz
Video adjustment	Brightness, Contrast, Saturation, Clarity
Record format	H.265+ IPC
Audio
Audio input	Integrated microphone
Audio output	External speaker
Audio compression	G.711A/U
Alarm
Alarm input	Yes
Alarm output	Yes
Network
Ethernet	Yes, 100/1000 Mbps RJ-45
Supported protocols	HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP
ONVIF	Yes
General characteristics
Pan/Tilt	Not
Infrared lighting	Yes
size	290 X 160 X 90 mm
Net weight	2.09 kg
SD card slot	MicroSD maximum 256GB (card not included)
Motion detection	Yes
Video recording	Locally, on SD and remotely on NVR
Optical zoom	16x
IR distance	up to 25 m
Send alarm notification to mobile phone	Yes
P2P	Yes
WDR (Wide Dynamic Range) function	Yes
Human form detection	Yes
Digital zoom	Yes
Human face detection	Yes
Vehicle detection	Yes
feeding
Supply voltage	12V or POE
The package contains
Chamber	Yes
User manual	Yes
Fixing screws	Yes
Operating parameters
fitting	Outside
Protection class	IP67
Operating temperature	-30 ~ +60°C
Storage temperature	-30°C ~ +60°C
Humidity in operation	10% - 90%
Moisture in storage	0%~95%
