PNI ML75 CB antenna, 75 cm, 300W, foldable and PNI SWR-300 reflectometer for SWR measurement, black
PNI-ML75FC - PNI ML75 CB antenna, length 75cm, 26-28MHz, 300W, foldable, without accessories
CB antenna without cableThe PNI ML75 CB antenna operates in the 26-28 MHz frequency range. It is 75 cm long and can communicate over a distance of up to 8 km (under ideal conditions of use). The PNI ML75 is perfect for drivers of TIRs, trucks or cars who want a product that ensures good communication in traffic. The SWR of less than 1.2:1 and the maximum power supported of 300W (for a short time) are essential specifications that recommend this product to the most demanding users. | |
PL type thread antennaWhen choosing a CB antenna, the following aspects must be considered:
The CB antenna is very important in the station - antenna assembly because the quality of the transmitted and received signal depends on it. The PNI ML75 CB antenna is one of the few PL antennas that can be tilted 90 degrees to enter passages, garages or low-height parking lots. | |
Compatible NIBP accessoriesThe PNI ML75 CB antenna with ø16mm thread is compatible with all PL type magnetic bases. For example: PNI 145/PL and with fixed mounting supports:
|
PNI-ML75FC - CB antenna PNI ML75, length 75cm, 26-28MHz, 300W, foldable, without accessories | |
---|---|
Product Identification | |
Product Code | PNI-ML75FC |
Working band | CB |
Product color (herringbone) | Silver |
Reel color | Black |
General characteristics | |
Operating frequency | 26 - 28 Mhz |
Maximum applied power | 40 W continuous / 300 W for short time |
Minimum S.W.R. in the center of the band | less than 1.2:1 |
Length | 750 mm |
Impedance | 50 Ohm |
Material | Stainless steel |
Connector type | PL |
Hole diameter | 16 mm |
Weight | 343 gr |
Dimensions | 750 X 40 X 40 mm |
Polarization | Vertical |
Working distance | 7 km |
Operating temperature | -26°C ~ +80°C |
Tiltable | Yes, up to 90 degrees |
Package contains | |
Radio antenna | Yes |
Rubber mount | Yes |
PNI-SWR300 - Reflectometer PNI SWR-300 PWR-SWR Meter, for measuring the SWR of radio antennas in 26-30Mhz frequency and CB radio station power | |
---|---|
Product identification | |
Product Code | PNI-SWR300 |
General Features | |
SWR measurement | Yes |
Power measurement | 0.5-10 W / 10-100 W |
Accuracy | SWR ± 5% / POWER ± 10% |
Frequency | 1.5-150MHz |
Dimensions | 85 X 76 X 58 mm |
Impedance | 50 Ohms |
Connector | SO 239 |
Package contains | |
Reflectometer | Yes |
User manual | Yes |
