PNI Safe House Dual Gas 250 kit with sensors for 2 types of carbon monoxide gas (CO) and natural gas and 3/4 inch solenoid valve
Always safePNI Safe House Dual Gas 250 ensures increased safety and comfort in the home or any space where there is the possibility of carbon monoxide or gas losses. Designed with two semiconductor sensors, one for CO and one for the other detected gases, PNI Safe House Dual Gas 250 is the ideal solution from all points of view: duration of use, versatility, high tolerance to extreme ambient conditions and corrosive environments. | |
Gas types detectedPNI Safe House Dual Gas 250 has the ability to detect: - carbon monoxide (CO), - natural gas (methane, propane, butane, ethane) - gaseous hydrocarbons (propylene, butylene). Attention, the gas sensor does not detect smoke, fire or gases from other categories than those mentioned above. | |
carbon monoxide (CO)Carbon monoxide (CO) is an odorless, colorless and tasteless gas, completely undetectable to human senses and very toxic. Carbon monoxide results from the incomplete combustion, in a place poor in oxygen, of fuels such as wood, coal, oil, kerosene, propane, natural gas, etc. Potential sources of CO can be: wood fuel stoves and fireplaces, gas stoves and power plants, oil or coal stoves, closed garages, etc. | |
Sound and light warningWith the help of the PNI Safe House Dual Gas 250 kit, you benefit from multiple warnings: both audible over 85dB and bright via the LEDs on the front In addition to the alarm status, they also indicate other functions of the device. | |
Complete packageBenefit from the advantage of purchasing a complete package of detection and safe interruption of the gas supply to a house. The package contains a gas sensor and an electrovalve. Power and connection cables are included. |
Video presentation |
|
Kit PNI Safe House Dual Gas 250 cu 2 senzori monoxid de carbon UK |
Product identification | |
Producer | PNI |
Product code | PNI-SH250 |
Gas sensor features | |
Gases detected | CO, natural gas, LPG, coal gas |
Energy consumption | maximum 3W |
Conditions of use | indoors only, humidity ≤ 95% |
Supply voltage | 230 |
Output voltage for the solenoid valve | 9-12V |
LEL (Lower Explosive Limit) | 7% |
Dimensions / Weight | Sensor: 72 X 33 X 123 mm / 200 g length of cable to electro-valve: 90 cm length of 230V supply cable: 140 cm Electrovalve: 65 x 45 x 105 mm / 380 g length of cable to sensor: 30 cm |
Sensor priming duration | 180 sec. |
Gas solenoid valve characteristics | |
Closing mode | Current pulse or manual |
Closing voltage | DC 9~12V (Impulse) |
Connection | 3/4" internal thread |
Maximum pressure | 100 kPa |
Operating temperature | -10ºC ~ +60ºC |
The package contains | |
Gas sensor | Yes |
Gas solenoid valve | Yes |
