PNI voltage inverter L1200W power supply 12V 230V output
| 220V socket and USB outputThe PNI L1200W inverter is equipped with a socket with an output of 230 V alternating current, modified sine wave for powering any electrical device, but also with a USB socket for charging, respecting the technical indications and the maximum allowed consumption. |
Multiple applicationsThe inverter can be used to power various electrical devices with resistive load such as: televisions, lighting lamps, radios, fans, mini-fridges, power supplies, as well as for charging compatible devices via USB cable: smartphone, mp3, tablet, etc. |
|
| Operating status warningThe status LEDs of the PNI L1200W inverter will warn you of the presence of error situations such as a discharged vehicle battery, overheating or overcharging of the device or will indicate its connection status to a power source. |
CompatibilityThe inverter can be used in any vehicle because it is designed to transform the voltage supplied by a 12 V battery into 230 V 50 Hz voltage. It is only used connected directly to the car battery. |
|
| Overheating protectionThe aluminum housing of the inverter and the built-in fan allow extremely efficient passive and active cooling, and operation at maximum capacity all the time. |
Incompatible with solar panelsCar inverters cannot be used with solar panels. There are special inverters for solar systems. |
|
Video presentation |
|
PNI L1200W power inverter video presentation |
| Product identification | |
| Exemplary | For resistive loads |
| Product code | PNI-H1200W12 |
| General characteristics | |
| Power output | 1200 W continuous |
| Peak output power | 2400W for 0.1S |
| Input voltage | 12V DC |
| Output voltage | 230V AC |
| Amperage on the 230V output | 0-5.2A |
| Active cooling | With fan |
| Recommended cable size | min 4mm |
| Output current (continuous) | 6 A |
| Maximum output current (for a short time) | 10 |
| Maximum output power | 2400W (for a short time) |
| Efficiency | 85% |
| USB port output | 5V / 1000mA |
| Output waveform | Modified sinusoid |
| size | 208 x 107 x 70 mm |
| Weight | 1914 g |
| Alarms and protections | |
| Overload protection | Yes |
| CONNECTIONS | |
| 230 V socket | 1 outlet |
| USB 2.0 | Yes |
| The package contains | |
| inverters | Yes |
| Power cord | Yes |
