Portable VHF / UHF radio station PNI P15UV dual band, 144-146MHz / 430-440Mhz, 999CH, with 1500 mAh battery

VHF-UHF dual band radio station. Functions: VOX adjustable squelch, TOT, BCL, Roger Beep, Key sound, key lock, frequency range scan. Frequency range: 144-146MHz & 430-440MHz.
£24.88
Availability: In stock
SKU
PNI-P15UV

Portable VHF/UHF radio station PNI P15UV

Dual band VHF / UHF

PNI P15UV is a communication tool within everyone's reach. Broadcasting on VHF and UHF radio frequencies is only possible with a radio frequency use license or a broadcast license. Reception in the VHF/UHF radio spectrum is free.

Amateur radio frequencies are used for non-commercial purposes, message exchange, experimentation, self-training, private recreation, radio sports, etc.

PNI P15UV operates in the frequency range 144-146MHz (VHF) & 430-440MHz (UHV).

Frequency mode (VFO) or channel mode (MR)

The station operates in several modes: UHF-VHF, VHF-VHF, UHF-UHF, in frequency mode or in channel mode. You can choose to display both frequencies or channels simultaneously on the screen (depending on the operating mode).

Portable VHF/UHF radio station PNI P15UV

Portable VHF/UHF radio station PNI P15UV

Customizable functions

PNI P15UV is a dual band station that offers maximum freedom to the user by customizing various functions: selectable transmission power (5W/1W), manual channel programming, manual frequency entry using the keyboard, scan mode selection, adding or excluding channels from scanning, precise frequency scanning by entering a specific frequency range, call encoding and decoding, SOS alarm (local, by code or sound), repeater tone selection, squelch adjustable on 9 levels, frequency step selection (2.5/5.0/6.25/10.0/12.5/20.0/25.0/50.0 KHz), etc.

Desktop charger included

Fix the PNI P15UV station in the desktop charger included in the package. Connect the charger power supply to a 230V power source. During charging, the LED on the charger is red and turns green when the battery is fully charged.

The 1500mAh Li-Ion battery can also be charged by direct connection to a power source via the micro USB Type-C port on the battery.

Portable VHF/UHF radio station PNI P15UV

Video presentation

Portable VHFUHF PNI P15UV dual band radio 144-146MHz / 430-440Mhz UK

Write Your Own Review
You're reviewing:Portable VHF / UHF radio station PNI P15UV dual band, 144-146MHz / 430-440Mhz, 999CH, with 1500 mAh battery
Your Rating
Product identification
Product code PNI-P15UV
Functions
Scan Yes
Timeout Timer Yes
BCL (Busy Channel Lockout) Yes
Expedite Yes
Squelch Yes
Hi/Low Power Yes
DTMF Yes
Dual watch Yes
Key lock Yes
Signal Strength Yes
VOX Yes
General features
Frequency VHF FM: 144-146 MHz; UHF FM: 430-440 MHz
Operating band UHF-VHF
Programmable channels 999 channels
Security codes 50 CTCSS / 208 DCS
Step frequency 2.5/5/6.25/10/12.5/25KHz
feeding 7.5 Vdc
Consumption ≤380mA in RX / ≤1600mA in TX
Battery capacity 1500mAh Li-Ion
Antenna impedance 50 Ohms
Operating temperature -26 ~ +80 degrees Celsius
Output power 5W
Audio output 1W @16 ohms
Weight 242 gr (antenna and battery included)
size 57 x 35 x 270 mm (antenna included)
Commercial FM radio frequency 87.5 - 108 MHz
LCD screen Yes
Headphone connector 2 pins PNI-K
The package contains
UHF and VHF radio station
Portable UHF and VHF radio station Yes
Battery Yes
User manual Yes
Desktop charger Yes
Belt holder Yes
Cord Yes
Programming cable



PNI-P15UV
Lang Type Name Link
EU10 Declaration of Conformity Declaration of conformity Link
EU10 User manual User manual EU10 Link
