RigExpert AA-35 ZOOM 0.06-35 MHz Antenna Analyzer, UHF Connector, Color Display
| Antenna analyzerThe AA-35 ZOOM is a portable, self-calibrating analyzer designed for measuring SWR (Standing Wave Ratio), testing, checking, adjusting or repairing antennas and antenna feed lines in the range from 60 kHz to 35 MHz. Graphical display of various parameters over a wide range of frequencies is a key feature of these analyzers. This significantly reduces the time required to tune an antenna. The ZOOM function even allows you to enlarge the graphic points for a clearer analysis. |
For radio amateurs or professional useEasy-to-use measurement modes, as well as additional functions, such as connecting to a computer, make the RigExpert AA-35 ZOOM attractive to both professionals and hobbyists. The analyzer is compatible with several operating systems, including Windows 10. |
|
| Power supply and PC connectionRigExpert AA-35 ZOOM can be powered with 2 AA alkaline batteries included in the package or with 2 AA Ni-MH batteries. Through the included USB cable, you can connect the analyzer to a computer both for power and for connection to the dedicated software, AntScope2. |
| Product identification | |
| Product code | PNI-AA-35 |
| Producer | RigExpert |
| Features | |
| Frequency range | 0.6 - 35 MHz |
| Frequency step | 1 kHz resolution |
| Compatible with | 25, 50, 75 and 100 Ohm systems |
| SWR measurement range | 1 - 100 in numerical mode / 1 - 10 in graphic mode |
| SWR display | Numeric and bars |
| Range R and X | 0...10000, -10000...10000 in numerical mode / 0...1000, -1000...1000 in graphic mode |
| RF output | UHF type connector (SO-239) |
| Output signal form | Square, 0.06 - 35 MHz |
| Power output | +13 dBm (at 50 Ohm load) |
| feeding | 2 AA alkaline batteries 1.5V / 2 AA Ni-MH batteries |
| Battery life (100% charged) | maximum 4 hours of continuous measurement or maximum 2 days in stand-by mode |
| Screen | Color TFT 320×240px |
| Water resistant keyboard | Yes |
| USB port | Yes, for PC connection and power supply |
| size | 103 x 207 x 37 mm |
| Weight | 310 g |
| Working temperature | 0°C ~ +40°C |
| Package contents | |
| Analyzer | Yes |
| Batteries | 2 AA alkaline batteries |
| USB cable | Yes |
| Belt pouch | Yes |
| User manual | Yes |
