SilverCloud YE910 electromagnetic yala, 12V, stainless steel, with double hub and button, Fail Secure NO, compatible with access control systems
Fail-secure actuation, NO - Normally Open | |
In this configuration, the lock opens with an electrical impulse of 12V 1A 0.5 seconds provided by a NO circuit (and closes only after the door or gate has been opened and closed) or manually (the mechanical components ensure opening from the inside even in the case of locks current). |
|
Universal opening | |
| The applicable electromagnetic lock SilverCloud YE910 can be mounted on doors opening on the right or left side, inward or outward. The recommended thickness of the door is between 35 and 50 mm. |
Compatible with intercom or access control systems | |
The electromagnetic Yala SilverCloud YE910 can be integrated into an access control or intercom system. The Unlock button on the internal unit of the video intercom in your home can unlock the door, thus allowing visitors access inside. |
|
Stainless steel | |
| Guaranteed for more than 200,000 openings, the YE910 electromagnetic lock is made of durable materials: stainless steel on the outside and brass (hub and latch). |
| Product identification | |
| Producer | Silvercloud |
| Product code | PNI-SCYE910 |
| Material | Stainless steel |
| General characteristics | |
| Type yala | Applied |
| Inside opening type | Electrical / Mechanical |
| Power supply voltage | 7 - 12V |
| Consumption | 50 - 60 W |
| Actuation type | Fail Secure ( Circuit NO / Normally Open) |
| Dimensions/Weight | 125 x 98 x 39mm / 1137g |
| Mode of application | Left/Right |
| Compatible with intercom and access control systems | Yes |
| Operating time | 0.5 s - 3 s at 12V |
| Lifetime | > 200,000 openings |
| Recommended thickness for the door | 35 - 50 mm |
| Working temperature | -26°C ~ +80°C |
| Retention system | Yes, type of furniture wheel |
| Mechanical unlocking system | Yes |
| Package Included | |
| Yala electromagnetic | Yes |
| Opening hub | Yes |
| Opening keys | 5 pcs. |
| Clamping system in the heel | Yes |
| Mounting accessories | Yes |
