SilverCloud YL500 Electromagnetic Yala with hub, left opening, Fail Secure NO
Fail-secure actuation, normally open | |
In this configuration, the lock opens with an electrical impulse of 12V 1A 0.5 seconds provided by a NO circuit (and closes only after the door or gate has been opened and closed) or manually (the mechanical components ensure opening from the inside even in the case of locks current). |
|
Opening on the left side | |
| The SilverCloud YL500 applicable electromagnetic lock can be mounted on doors opening on the left side inwards. The recommended thickness of the door is between 35 and 50 mm. |
Compatible with intercom or access control systems | |
The electromagnetic Yala SilverCloud YL500 can be integrated into an access control or intercom system. The Unlock button on the internal unit of the video intercom in your home can unlock the door, thus allowing visitors access inside. |
|
| Product identification | |
| Producer | Silvercloud |
| Product code | PNI-SCYL500 |
| Material | Satin nickel |
| General characteristics | |
| Type yala | Applied |
| Inside opening type | Electric |
| Power supply voltage | 7 - 12V |
| Consumption | 2 - 3.5 A at 12V |
| Actuation type | Fail Secure ( Circuit NO / Normally Open) |
| Dimensions/Weight | 125.5 x 101 x 39mm / 1000g |
| Mode of application | Left |
| Compatible with intercom and access control systems | Yes |
| Operating time | 0.5 s - 3 s at 12V |
| Lifetime | > 200,000 openings |
| Recommended thickness for the door | 35 - 50 mm |
| Working temperature | -20°C ~ +55°C |
| Retention system | Yes, mobile tongue/puppy |
| Package Included | |
| Yala electromagnetic | Yes |
| Opening hub | Yes |
| Opening keys | 3 pcs. |
| Clamping system in the heel | Yes |
