Smart thermostat PNI CT25W WiFi for gas heating plant, recessed mounting, 16A, control from the Tuya Smart application, daily programming, manual/automatic mode, white color
|
Local or remote controlThe PNI CT25W built-in smart thermostat with WiFi can be controlled remotely through the Tuya Smart app. Thus, from wherever you are and have an internet connection, you can turn the heating system on or off, set operating modes and schedules or change certain parameters. |
CompatibilityThe PNI CT25W built-in smart thermostat is compatible with any brand of underfloor water heating system, water pumps or residential gas boilers. The thermostat has a non-energized relay type output (Dry contact). |
|
Modes of operationSet the operating schedule of the heating system for each day of the week, 4 periods per day or choose the manual operating mode, so that the heating system will try to keep the set temperature for the entire duration of 24 hours. |
|
Floor sensor inputThe PNI CT25W smart thermostat is equipped with an input for an additional floor sensor. Thus, in addition to the built-in air sensor, you can also connect an external wired sensor that detects and transmits the temperature at floor level to the central unit. The temperature displayed by default on the screen is the temperature of the air in the room. With the help of this floor sensor (purchased separately) the thermostat can work in 2 ways: depending on the air sensor or depending on the floor sensor. |
Product Identification | |
Product code | PNI-CT25W |
General characteristics | |
Product Type | Wired thermostat and Internet control |
Intended for | Underfloor heating, Heating plants |
Compatible brand | Universal |
Mounting | In dose |
Material | ABS + glass |
Color | White |
Connectivity | - Wireless to Internet router: WiFi 802.11b/g/n (2.4 GHz); WPA2 (TKIP and AES) - Floor sensor input |
Power Supply Type Input Voltage | 230V AC |
Operating Parameters | - Set temperature range: 1 - 35°C - Desired temperature setting step: 0.5°C - Measured temperature range: 1 - 99°C - Displayed temperature step: 0.5°C - Unit of measurement: Degrees Celsius - Adjustable hysteresis: 0.5°C - 5°C |
Functions | - WIFI connection to the Internet - Floor or ambient temperature monitoring - Control from the mobile app - Hourly, daily scheduling - Screen brightness setting - Child protection |
Dedicated smartphone app | Tuya Smart / Smart Life |
Configurable parameters | - Temperature sensor calibration - Minimum and maximum adjustable temperature - Upper/lower temperature limit -Hysteresis |
Dimension | 86 X 86 X 36 mm |
Output Type Output Voltage | - Non-energized relay output Dry contact (DC/AC 16A maximum), also compatible with central heating systems |
The package contains | |
Thermostat | Yes |
Mounting accessories | Mounting Screws |
![]() PNI-CT25W |
|
