Switch POE PNI SWPOE162, 16 POE 100 Mbps ports, 2 UP Link 1000 Mbps ports, 1 SFP 1000Mbps port, 240W, AI Extend function up to 250m, 4kV lightning protection

Switch POE PNI SWPOE162, 16 POE 100 Mbps ports, 2 UP Link 1000 Mbps ports, 1 SFP 1000Mbps port, 240W, AI Extend function up to 250m, 4kV lightning protection
£74.65
Availability: In stock
SKU
PNI-SWPOE162

POE switch PNI SWPOE162, 16 POE ports

PoE switch (Power over Ethernet)

The PNI SWPOE162 PoE switch is a network device that allows both data transfer and power supply to devices connected via the same Ethernet cable.

PoE switches are frequently used in video surveillance networks and, in general, in modern IT systems.

AI Extend function

The AI Extend function allows the transmission distance to be extended up to 250 meters, making it perfect for situations where cables need to cover distances greater than the standard 100m limit.

POE switch PNI SWPOE162, 16 POE ports

POE switch PNI SWPOE162, 16 POE ports

Connectivity capabilities

16 PoE ports with 100 Mbps speed – These are standard Ethernet ports that allow both 100 Mbps data transfer and powering of connected devices.

2 x 1000 Mbps UP Link ports – These are dedicated ports for connecting the switch to other network equipment, such as a router, another switch, or a server. Unlike PoE ports, these do not provide power, but have a higher data transfer speed.

1 1000 Mbps SFP port – This port is for SFP (Small Form-factor Pluggable) modules, used for fiber optic connections.

Write Your Own Review
You're reviewing:Switch POE PNI SWPOE162, 16 POE 100 Mbps ports, 2 UP Link 1000 Mbps ports, 1 SFP 1000Mbps port, 240W, AI Extend function up to 250m, 4kV lightning protection
Your Rating
Features
Number of ports 16 x POE 100 Mbps + 2 x 1000 Mbps LAN + 1 x 1000 Mbps SFP
Transfer Rate 10/100/1000 Mbps
Connector Type RJ-45
Supported standards IEEE 802.3 Ethernet Media Access Control Protocol; IEEE 802.3i 10BASE-T Ethernet; IEEE 802.3u 100BASE-TX Fast Ethernet; IEEE 802.3af; IEEE 802.3t; IEEE 802.3x.
Data transfer latency 1.2G
Bandwidth 1.2G
Data transfer rate Ethernet 10Mbps half duplex, 20Mbps full duplex; Fast Ethernet 100Mbps half duplex, 200Mbps full duplex;
Maximum transfer distance 100Base-TX:2 CAT5 or higher UTP/STP (≤ 100m); 10Base-TX:2 CAT5 or higher UTP/STP (≤ 250m);
Supply voltage 100-250V 50/60Hz
Dimensions 270 X 180 X 45 mm
Weight 1,354 kg
Ambient temperature -26°C ~ +80°C
PoE Standard 16 x POE 100Mbps
PoE Power Mode 52V DC max. 240W (total); 30W (per port)
Lightning protection 4KV
POPPY 2K
The package contains
Feeder
Power Cord Yes
Rack mounting clamps Yes
Switch Yes
Textbook Yes



PNI-SWPOE162
Lang Type Name Link
EU10 Declaration of Conformity Declaration of Conformity Link
EU10 User manual User manual EU10 Link
