Switching voltage source PNI ST3.4A 230V to 12V 3.4A stabilized for surveillance systems

PNI ST1922 voltage source, 230V AC input, 12V DC output, 5A

PNI ST1922 voltage source, 230V AC input, 12V DC output, 5A

Switching voltage source PNI ST20A Plus 230V to 12V 20A stabilized for surveillance systems

Be the first to review this product
Switching voltage source 12V 20A stabilized for access control and surveillance systems.
£9.95
Availability: In stock
SKU
PNI-ST20AP
Add to Wish List Add to Compare

Sursa de tensiune in comutatie PNI ST20A Plus

Use

The PNI ST20A Plus power supply can be used in access control systems, video surveillance systems or in any application with consumption less than 20A.

Supply voltage

The PNI ST20A Plus voltage supply is supplied to the normal electricity grid with a voltage of 230V.

Sursa de tensiune in comutatie PNI ST20A Plus

Sursa de tensiune in comutatie PNI ST20A Plus

Output

PNI ST20A Plus has two 12V outputs and a total maximum capacity of 20A.

Physical characteristics

The base plate of the power supply is protected by a shock-resistant metal housing. Due to its small size, it can be easily mounted and hidden in a junction box. It has the dimensions: 198 x 97 x 42 mm.

Sursa de tensiune in comutatie PNI ST20A Plus



Video presentation

PNI Switched Voltage Source ST20A Plus 12V 20A stabilized for Surveillance Systems UK
Write Your Own Review
You're reviewing:Switching voltage source PNI ST20A Plus 230V to 12V 20A stabilized for surveillance systems
Your Rating
Product Identification
Product code PNI-ST20AP
Manufacturer NIP
Features
Input voltage 110/230V AC selectable
Input Signal Frequency 50-60Hz
Output voltage 2 x 12V
Output Current 20A (peak)
Power output 240W
Overload protection From 105% to 115%
Operating temperature -26°C ~ +80°C
Dimensions (D x H x W) / Weight 198 x 97 x 42 mm / 683g
Efficiency 73%
Short circuit protection Yes
Cooling fan Yes
The package contains
Power Supply Yes
User Manual Yes



PNI-ST20AP
Lang Type Name Link
EU Declaration of Conformity Declaration of conformity EN-BG-DE-ES-FR-HU-IT-PL-RO Link
EU10 Declaration of Conformity Declaration of conformity EU10 Link
EU10 User manual User manual EU10 Link
