Three-phase meter ORNO OR-WE-520, 80A, MID certification, 3 phases, 230V, measurement class B, pulse frequency 800 imp/kWh, IP51, gray

Write Your Own Review

Identification
Product code	OR-WE-520
General Features
Technical parameters	Type: three phases Power supply: 3 x 230V / 400V ~, 50 / 60Hz Basic current: 5A Maximum current (lmax): 80A Min. current: 0.25A Pulse frequency: 800 imp / kWh Measurement accuracy class: B Conformity with intermediate certificate (2014/32/eu) Display: 6 + 2 Pulse output: yes Number of modules: 4.5 Protection rating: IP51
Description	Device for displaying in metric units (kWh). It is used for the direct measurement of active power in a three-phase system. Special electronic components under the influence of the current flow and the applied voltage generate impulses proportional to the absorbed energy. The energy consumption phase is indicated by a flashing LED. The number of pulses is transformed into input energy and its value is indicated by the LCD screen (6 + 2). The energy measurement is carried out in accordance with the standards EN50470-1: 2006, EN50470-3: 2006 MID Directive 2014/32 / EU.
Weight	372 gr
size	75 X 65 X 100 mm
The package contains
Content	Three-phase meter
