Video surveillance kit PNI House WiFi550 NVR 8 Channel 1080P and 4 Wireless Wireless Outside 720P, P2P, IP66
Access and control methodsThe PNI House WiFi550 video surveillance kit can be controlled from mobile devices through the Danale application compatible with Android and iOS, and from PC through the Dana CMS software. You can find the CMS installation file on the CD included in the package or you can download it from our website, from the product page, Download section. | |
Wireless communicationYou can connect the camera to the Internet through a wireless network. Also, connect the camera to the NVR also via a wireless connection. The maximum WiFi transmission distance is 100 m (in open field). | |
4 exterior roomsThe PNI House WiFi550 kit contains a recording unit (NVR) and 4 cameras, which can be used both indoors and outdoors, allowing surveillance of your home or business from anywhere you have an Internet connection. | |
8 channel NVRWith the NVR in the package, you can record and play back images from 8 full HD video surveillance cameras. To record images, you can mount an internal HDD with a capacity of up to 4TB inside the NVR. | |
Recording at nightThe 4 cameras are equipped with 30 IR LEDs each, equipment that offers you a quality video at night, up to 30 m. | |
Internet controlNow you can watch in real time the images taken by PNI House WiFi550. We also add full access to the system that allows you: settings, view recordings, download recordings, etc. Also, for a simpler configuration, the NVR in the kit can be accessed from the Internet without the need for special configurations in your router, through a P2P connection. For Android and iOS we recommend the Danale application. | |
View in real timeThe images are recorded in real time and can be viewed through a monitor connected to the NVR through the VGA or HDMI interface. | |
HDD compatibilityAlong with the evolution of surveillance systems, HDD manufacturers have created dedicated solutions for them. Thus, for maximum performance of surveillance systems, we recommend using only hard disks dedicated to surveillance systems. |
Video presentation |
|
PNI House WiFi550 Video Surveillance Kit |
Product identification | |
Producer | PNI |
Product code | PNI-WF550 |
DVR/NVR Color | Black |
Room color | White |
DVR/NVR features | |
Video inputs | 8 entries |
Video outputs | 1 x VGA, 1 x HDMI |
Playback resolution | 4 x 960P |
Registration resolution | |
Display mode | 1/4/9 |
Video compression | H.264 |
Data storage | maximum 2 x 4 TB HDD (not included) dedicated to video surveillance |
Network interface | RJ45 10/100 Mbps |
Firmware update | Yes, via USB |
Remote control | |
Power supply voltage | 12V/2A |
Operating temperature | -26°C ~ +80°C |
size | 260 x 220 x 40 mm |
Number of channels | 8 channels 1080P |
Video output resolution | 1080P, 960P, 720P, 960H, D1, 360P, VGA |
Processor | Hi3520D |
Wifi | Yes, only for connecting cameras |
USB ports | 2 x USB2.0 |
Dedicated application | Danale |
Camera features | |
Image sensor | 1/4" CMOS |
PIXEL | 1280 x 720 (HD) |
Video output | Digital, via RJ45 |
Minimal lighting | 0.01 LUX @ F1.2 |
Consumption | max. 6W |
Degree of protection | IP66, metal housing |
IR illumination distance | Up to 30 m |
size | 60 x 183 x 60 mm (stand included) |
Weight (without accessories) | 400 g |
Number of IR LEDs | 30 |
feeding | 12V / 1A |
LENS | 3.6 mm |
Network interface | RJ45 10/100Mps |
Wifi | Yes |
Operating temperature | -25 ~ +50°C |
The package contains | |
DVR / NVR | Yes |
Surveillance cameras | 4 indoor/outdoor rooms |
NVR / DVR power supply | Yes |
Software CD | Yes |
User manual | Yes |
USB mouse | Yes |
Remote control | |
Camera power supply | Yes |
Ethernet cable | Yes |
PNI-WF550 |
|
