Video surveillance kit PNI House WiFi650 - 4 Full HD Wi-Fi P2P and 12-inch LCD monitor
Access and control methodsThe PNI House WiFi650 video surveillance kit can be controlled from mobile devices through the XMEye application compatible with Android and iOS, or through the General CMS (Windows) / VMS (MAC) software. You can find the CMS installation file on the CD included in the package or you can download it from our website, from the product page, Download section. Through the dedicated applications, you can watch in real time the images taken by the cameras, to which is added the full access to the system that allows you: settings, viewing recordings, downloading recordings, etc. | |
Wireless communicationYou can connect the camera to the Internet through a wireless network. Also, connect the camera to the NVR also via a wireless connection. The maximum Wi-Fi transmission distance is 100 m (in open field). | |
4 channel 1080P NVRYou can connect 4 IP 1080P cameras or 8 IP 960P cameras to this system. For registration, you must install a 2.5-inch hard disk of maximum 8TB in the dedicated slot. The hard disk is not included in this kit. | |
Visibility at nightThe cameras are equipped with 3 IR LEDs that allow visibility even at night up to a distance of 30 m. | |
12" monitor includedThe kit includes a monitor with a 12-inch LCD screen, with a slot for installing a 2.5-inch hard disk and ports such as: VGA and HDMI for connecting another external monitor, USB for connecting a mouse and stick in case of a firmware update and RJ45 for connecting the system to the Internet. |
Video presentation |
|
Video surveillance kit PNI House WiFi650 4 Full HD Wi Fi P2P and 12 inch LCD monitor |
Product identification | |
Producer | PNI |
Product code | PNI-HSWIFI450 |
Room color | White |
DVR/NVR features | |
Video inputs | 4 x 1080P (25FPS) |
Video outputs | 1 x VGA, 1 x HDMI |
Playback resolution | 1080P Full HD |
Registration resolution | 1080P Full HD (4 channels) |
Display mode | 1 channel, 4 channels |
Audio compression | G711A |
Video compression | H.265+ / H.265 / H.264+ / H.264 |
Data storage | maximum 1 x 8 TB HDD 3.5 |
Network interface | RJ45 10/100 Mbps |
Supply voltage | 12V/2A |
Operating temperature | -10°C ~ +40°C |
size | 294 x 188 x 45 mm |
Number of channels | 4 digital |
Video output resolution | 1920 x 1080 px |
Recording resolution and number of channels, variants | 4 channels 1080P 8 channels 960P |
Processor | Hi3536D |
Wifi | Yes, only for connecting cameras |
Wireless communication distance | Up to 100m in open space |
USB ports | 2 x USB2.0 |
Screen | 12 inches |
Dedicated application | XMEye |
Network | Yes, RJ45 LAN Port |
Registration methods | Manual, programmed, alarm |
Motion detection | Yes |
Camera features | |
Image sensor | 1/2.9” 2MP CMOS |
Video system | PAL/NTSC |
PIXEL | 1920×1080 |
Resolution | 1080P |
Video output | Digital, via RJ45 |
Minimal lighting | 0 Lux (IR on) |
Degree of protection | IP67 |
IR wavelength | 850 nm |
IR illumination distance | Up to 30 m |
size | 60 x 65 x 180 mm |
Number of IR LEDs | 3 |
feeding | 12V / 1A |
LENS | 3.6 mm |
Wifi | Yes |
Operating temperature | -26°C ~ +80°C |
Dedicated application | XMEye |
Sensor resolution | 2MP |
The package contains | |
DVR / NVR | Yes |
Surveillance cameras | 4 indoor/outdoor rooms |
NVR / DVR power supply | 230V -> 12V 2A |
Software CD | Yes |
User manual | Yes |
USB mouse | Yes |
Camera power supply | 230V -> 12V 1A |
Monitor features | |
Display | 12 inches |
Display type | TFT-LCD |
Display size | 256.32 x 114.18 mm |
Touch screen | Not |
