Voltage source with timer PNI K80 12V and 3A for. yale and access control

Voltage source with timer PNI K80 for yale and access control.

£18.31

Availability: In stock

SKU

PNI-K80

	Applications PNI K80 is a power supply with timing that can be used in access control systems, video surveillance systems or in any application with consumption less than 3A.
entry The PNI K80 source is supplied with a voltage that can vary between 110 and 260 V and has a 12V output.
	DELAY The source is equipped with an output delay circuit which is very useful when using the source to power a lamp where you need it to stay open for a few seconds. Insert a flat screwdriver and turn clockwise or anticlockwise to set the timer between 0 and 15 seconds.
Physical characteristics The main board of the power supply is protected by a shock-resistant metal housing. Due to its small dimensions, it can be easily mounted and hidden in a junction box. It has the dimensions: 120 x 95 x 38 mm.
Connection diagram

Video presentation
Access control power source, power supply PNI K80 AC 110 260V to DC 12V 3A UK

Product identification
Producer	PNI
Product code	PNI-K80
Type	Power supply
Features Card reader
Operating temperature	-26°C ~ +60°C
Power supply characteristics
Source type	In switching
Input voltage	110 - 260V
Output voltage	12Vdc
Maximum output current	3A
Power	35W
Operating temperature	-20 to +60 degrees C
size	120 x 95 x 38 mm
Weight	315g
The package contains
Power supply	Yes
User manual	Yes

PNI-K80

Lang	Type	Name	Link
EU	Declaration of Conformity	Declaratie de conformitate EN, BG, DE, ES, FR, HU, IT, PL, RO	Link
EU10	Declaration of Conformity	Declaration of conformity EU9	Link
EU10	User manual	User manual	Link
RO	Declaration of Conformity	DC&CG	Link
