Wireless CB PNI Escort Pack HP 6500 ASQ + CB PNI S75 Antenna

Be the first to review this product

£66.35

Availability: In stock

SKU

PNI-PACK62

Details

Small dimensions Its small dimensions (only 110x120x25mm) allow the station to be placed even in very narrow spaces, without the need to resort to a real installation, such as in the case of a classic CB.
	Emission power 4W The station complies with the legislation in force in Romania, harmonized with European norms, with a maximum legal power of 4 W.
FM/AM The PNI Escort HP 6500 CB station allows communication in the FM band, used in Romania, but also in the AM band, when traveling outside the country. In addition to the band type, the station also allows the selection of the frequency band, a setting necessary for using the station in other European countries.
	Dual, adjustable and automatic digital squelch The PNI Escort HP 6500 is enhanced with a digital automatic noise and interference reduction system (Digital Automatic Squelch). The manual and automatic double squelch mode offers 28 and 9 level adjustments along with the RF Gain function for finer reception adjustment.
CB antenna performance The performance of the product is closely related to the technical characteristics of the antenna under ideal conditions of installation and use: SWR <= 1.2:1, maximum applied power 250 W, impedance 50 Ohms, stainless steel, etc.
	Communication distance The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of 10 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the maximum legally allowed power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can lead to a decrease in this distance.
Antenna length The length of the antenna is another very important factor that can influence the communication distance in traffic. Thus, the longer the antenna, the greater the range. The antenna in this kit has a length of 76 cm (magnetic base included).
	Adjustable angle This antenna can be tilted using the included thumbscrew to enter low-height passages, garages, or parking lots. Outside of these situations, a tilt greater than 30 degrees is not recommended as it may affect the antenna's performance.

Reviews

Technical specifications

Product identification
Product code	PNI-PACK62
General characteristics of the radio station
Exemplary	Furniture
Emission band type	AM-FM
Frequency	26.965-27.405 MHz
channels	40 AM/FM
Speaker audio power	1W
Sensitivity (20dB SINAD)	greater than 1 µV (AM/FM)
Emission power	4W
Modulation	80 - 90%
feeding	12V
Consumption	2A maximum
Dimensions / Weight	110 X 120 X 28 / 385 g
Special features of the radio station
Channel scan	Yes
RF Gain	Yes, 9 levels
Keyboard lock	Yes
Emergency channel button 9/19	Yes
Adjustable ASQ	Yes, 28 levels
SQ - Squelch	Yes
Radio antenna features
Working frequency	26 - 28 MHz
Number of channels	40
Maximum applied power	250W
Minimum SWR in the center of the band	less than 1.2
Antenna length	76 cm including base
Working distance	10 km
Impedance	50 Ohms
Material	Stainless steel
Connector type	your
Magnetic base included	Yes
Magnetic base diameter	125mm
Cable length	4m
The package contains
CB radio station	Yes
CB radio antenna	Yes
Magnetic base	Yes
PL259 plug	Yes
RG58 cable	Yes, 4 m
