Wireless CB PNI Escort package HP 6500 ASQ + CB PNI ML100 antenna
Reduced dimensionsIts small dimensions (only 110x120x25mm) allow the station to be placed even in very narrow spaces, without having to resort to a real installation, as in the case of a classic CB. | |
Emission power 4WThe station complies with the legislation in force in Romania harmonized with European standards, having the maximum legal power allowed of 4 W. | |
FM/AMThe PNI Escort HP 6500 CB station allows communication in the FM band, used in Romania, but also in the AM band, when traveling abroad. In addition to the band type, the station also allows the selection of the frequency band, a setting necessary for using the station in other European countries. | |
Double squelch, adjustable and automatic digitalPNI Escort HP 6500 is improved with a digital automatic system for reducing noise and interference (Digital Automatic Squelch). The dual manual and automatic squelch mode offers 28 and 9 level settings along with the RF Gain function for a finer reception adjustment. | |
CB antenna performance PNI ML100The performance of the product is closely related to the technical characteristics of the antenna in ideal conditions of installation and use: SWR <= 1.0, maximum power applied 250 W continuously, impedance 50 Ohms, stainless steel, etc. | |
Communication distanceThe communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 12 km is achieved under ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance. | |
Antenna lengthThe length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML100 antenna is 110 cm long (magnetic base included). | |
Magnetic baseThe magnetic base 120/PL in the package is provided with a 4 m cable, enough to place the antenna on the dome, it has a diameter of 125 mm and a strong magnet that gives the antenna stability even at high speeds. |
Video presentation |
|
CB PNI ML100 antenna EN |
Product identification | |
Product code | PNI-PACK63 |
General characteristics of the radio station | |
Exemplary | Portable |
Emission band type | AM-FM |
Frequency | 26.965-27.405 MHz |
channels | 40 AM/FM |
Speaker audio power | 1W |
Sensitivity (20dB SINAD) | greater than 1 µV (AM/FM) |
Emission power | 4 W |
Modulation | 80 - 90% |
feeding | 12 V |
Consumption | 2A maximum |
Dimensions / Weight | 110 X 120 X 28 / 385 g |
Special radio station features | |
Channel scan | Yes |
RF Gain | Yes, 9 levels |
Lock the keyboard | Yes |
Emergency channel button 9/19 | Yes |
Adjustable ASQ | Yes, 28 levels |
SQ - Squelch | Yes |
Characteristics of the radio antenna | |
Working frequency | 26 - 28 Mhz |
Number of channels | 90 |
Maximum power applied | 250 W |
Minimum SWR in the center of the band | 1.0 |
Antenna length | 100 cm (110 cm with base included) |
Working distance | 10 km |
Impedance | 50 Ohms |
Material | Stainless steel |
Connector type | PL259 |
Hole diameter | 16 mm |
Magnetic base included | Yes |
Magnetic base diameter | 125 mm |
Cable length | 4 m |
The package contains | |
CB radio station | Yes |
CB radio antenna | Yes |
Magnetic base | Yes |
Plug PL259 | Yes |
RG58 cable | Yes, 4 m |
